static uint8_t const sin = 0;
static uint8_t const tri = 1;
static uint8_t const saw = 2;
static uint8_t const pwm = 3;

uint32_t phase;
int32_t phasor;
int32_t phaseCounter;
uint32_t r;
int32_t a;
int32_t b;

phase = 0;
phasor = 0;
phaseCounter = 0;

r = 1;
a = 0;
b = 0;

uint32_t freq;
MTOFEXTENDED(param_pitch + inlet_pitch, freq);

int32_t shape;
shape = __USAT(param_shape + (___SMMUL(param_amount, inlet_shape) << 1), 27);

int32_t waveform;
waveform = (param_waveform + (inlet_wave >> 4)) % 4;

/* reset phase if retriggered */
if (inlet_reset && r) {
  phase = 0;
  phaseCounter = 0;
  r = 0;
} else {
  if (!inlet_reset)
    r = 1;
  phase += (freq >> 0) + inlet_freq;
  /* if new phasor value is smaller then last one -> increment phaseCounter */
  a = phase >> 5;
  /* first or second phase cycle */
  if (a < phasor) {
    phaseCounter++;
    if (phaseCounter == 2)
      phaseCounter = 0;
  }
  /* set new phasor value */
  phasor = a;
}

/* calculate waveforms based on phasor value */
switch (waveform) {
case sin:
  /* phasor to sine */
  SINE2TINTERP(phasor << 5, a) /* calculate sine wave via function */
  outlet_out = (a >> 4);
  break;

case tri:
  /* phasor to triangle */
  b = (phasor > 0x07FFFFFF / 4)
          ? phasor - 0x07FFFFFF / 4
          : phasor +
                0x07FFFFFF / 4 * 3; /* phase shift to correct wave startpoint*/
  a = (b - (1 << 26))
      << 1; /* phasor to sawUp (bipolar) -> -a = sawDown (bipolar) */
  a = (a > 0) ? a : -a; /* merge sawUp and sawDown to triangle -> unipolar */
  a = (a - (1 << 26)) << 1; /* unipolar to bipolar */
  b = 0x07FFFFFF - (shape / 10 * 8);
  a = (a > b || a < -b) ? -a + ((a > 0) ? 2 : -2) * b
                        : a; /* param_shape threshold for wavefolding */
  outlet_out = a;
  break;

case saw:
  /* phasor to saw */
  b = (phasor > 0x07FFFFFF / 2)
          ? phasor - 0x07FFFFFF / 2
          : phasor + 0x07FFFFFF / 2; /* phase shift to correct wave startpoint*/
  a = (b - (1 << 26)) << 1;          /* phasor to sawUp (bipolar) */
  outlet_out = (phaseCounter == 1 && (phasor > 0x07FFFFFF / 2 - shape / 2 &&
                                      phasor < 0x07FFFFFF / 2 + shape / 2))
                   ? -a
                   : a;
  break;

case pwm:
  /* phasor to pulse width */
  outlet_out = (phasor >= 0x07FFFFFF / 2 + shape / 2)
                   ? -0x08000000
                   : 0x07FFFFFF; /* pulse width depending on shape value*/
  break;
}
