par_swap_2
Stereo swappable parallel routing switch
IO Variants: 2
Variant: 1
Inlets
bool32 Swap device 1 and 2 outputs
frac32buffer Input 1 L
frac32buffer Input 1 R
frac32buffer Input 2 L
frac32buffer Input 2 R
Outlets
frac32buffer Output 1 L
frac32buffer Output 1 R
frac32buffer Output 2 L
frac32buffer Output 2 R
Parameters
frac32.u.map.squaregain Device 1 volume
frac32.u.map.squaregain Device 2 volume
int32_t j, outl, outr;
if (inlet_swap) {
for (j = 0; j < BUFSIZE; ++j) {
// Feed input 1 to out 2
// Feed input 2 to out 1
outlet_o1l[j] = ___SMMUL(inlet_i2l[j] << 3, param_dev2vol << 2);
outlet_o1r[j] = ___SMMUL(inlet_i2r[j] << 3, param_dev2vol << 2);
outlet_o2l[j] = ___SMMUL(inlet_i1l[j] << 3, param_dev1vol << 2);
outlet_o2r[j] = ___SMMUL(inlet_i1r[j] << 3, param_dev1vol << 2);
}
} else {
for (j = 0; j < BUFSIZE; ++j) {
// Feed input 1 to out 1
// Feed input 2 to out 2
outlet_o1l[j] = ___SMMUL(inlet_i1l[j] << 3, param_dev1vol << 2);
outlet_o1r[j] = ___SMMUL(inlet_i1r[j] << 3, param_dev1vol << 2);
outlet_o2l[j] = ___SMMUL(inlet_i2l[j] << 3, param_dev2vol << 2);
outlet_o2r[j] = ___SMMUL(inlet_i2r[j] << 3, param_dev2vol << 2);
}
}Variant: 2
Inlets
frac32buffer Input 1
frac32buffer Input 2
bool32 Swap device 1 and 2 outputs
Outlets
frac32buffer Output 1
frac32buffer Output 2
Parameters
frac32.u.map.squaregain Device 1 volume
frac32.u.map.squaregain Device 2 volume
int32_t j, out;
if (inlet_swap) {
for (j = 0; j < BUFSIZE; ++j) {
// Feed input 1 to out 2
// Feed input 2 to out 1
outlet_o2[j] = ___SMMUL(inlet_i1[j] << 3, param_dev1vol << 2);
outlet_o1[j] = ___SMMUL(inlet_i2[j] << 3, param_dev2vol << 2);
}
} else {
for (j = 0; j < BUFSIZE; ++j) {
// Feed input 1 to out 1
// Feed input 2 to out 2
outlet_o1[j] = ___SMMUL(inlet_i1[j] << 3, param_dev1vol << 2);
outlet_o2[j] = ___SMMUL(inlet_i2[j] << 3, param_dev2vol << 2);
}
}
