static const uint8_t FRAME_SIZE =
    64; // Frame size (energy is calculated on 1 frame, etc.)
static const uint8_t NB_CHUNK_FRAME =
    4; // 16 samples for k-rate call, then 4 calls for a 64 samples frame
static const uint8_t INITTIMER =
    128; // Nb frames while attack or silence detection are desactived
static const uint32_t HANINC =
    33554432; // Increment of the half hanning window use for fadein and fadeout
              // : MAX_INT / 2 / FRAME_SIZE
static const uint32_t HANMID =
    2147483648; // Index of the middle of the hanning window

uint8_t preset = 0;        // Used for rising edge logic on reset inlet
uint32_t si = 0;           // slice buffer current index
uint32_t sii = 1;          // slice index current index
float energy = 0.f;        // root mean square value of the current frame
float power_decibel = 0.f; // root mean square value of the current frame in
                           // decibel (rms reference = 1)
float power_decibel_prev = 0.f; // root mean square value of the current frame
                                // in decibel (rms reference = 1)
uint16_t timer = 0;     // A simple timer, for mask consecutive attack detection
uint8_t crosscheck = 0; // true <==> zero crossing check activate
uint32_t zerocrosspoint = 0; // zero crossing index in wave table
int32_t
    twoframe[2 * FRAME_SIZE]; // Buffer used for temporary continuous recording
uint8_t tfi = 0;              // Two frame buffer index
uint8_t curchunk = 0;         // Current chunk number
uint8_t detect = 0;       // Detection status : 1 => store slice in slicebuffer
float peakenvelope = 0.f; // Current envelope value expressed in decibel
float delta = 0.f;        // For attackstep calibration output
float power_db_threshold =
    0.f; // [user] Decibel absolute threshold for attack test
float delta_power_db =
    0.f; // [user] Threshold for attack detection on difference of previous
         // peakenvelope and current peakenvelope
float silence_db_threshold = 0.f; // [user] Decibel threshold for silence test
float timeconstant =
    0.f;            // [user] Attribute used for computing the decay factor
float radius = 0.f; // The decay factor
uint8_t trig = 0;
uint8_t confmode = 0;

/* Float <-> Fixed Point conversion */
__attribute__((always_inline)) __STATIC_INLINE float q_to_float(int32_t op1,
                                                                int q) {
  float fop1 = *(float *)(&op1);
  __ASM volatile("VCVT.F32.S32 %0, %0, %1" : "+w"(fop1) : "i"(q));
  return (fop1);
}

__attribute__((always_inline)) __STATIC_INLINE int32_t float_to_q(float op1,
                                                                  int q) {
  __ASM volatile("VCVT.S32.F32 %0, %0, %1" : "+w"(op1) : "i"(q));
  return (*(int32_t *)(&op1));
}

// For display a value each second : if(!calib_cpt) LogTextMessage("val : %d",
// val);

/*  Apply an half Hanning window on the begin of the recorded sample (2 frames)
 *  Hanning is full range (input in range 0..MAX_INT).
 *  Start on the begin of the hanning window and finish on the middle the
 * hanning window.
 */
void insert_twoframe(void) {
  int32_t s = 0;
  uint32_t phase = 0;
  int8_t tfitmp = tfi;
  int32_t r;
  int8_t i;

  for (i = 0; i < FRAME_SIZE; i++) {
    HANNING2TINTERP(phase, r)
    /* "<< 5" to complete ___SMMUL operation (fixed point choice contraint)
     * ">> 4" => just a copy of the hanning window axoloti object. Why not >> 5
     * ? I don't understand.
     */
    s = ___SMMUL(twoframe[tfitmp], r >> 4) << 5;
    attr_slicesbuffer.array[si] = __SSAT(s, 28) >> attr_slicesbuffer.GAIN;
    tfitmp++;
    si++;
    tfitmp %= FRAME_SIZE * 2;
    phase += HANINC;
  }
  for (i = 0; i < FRAME_SIZE; i++) {
    s = twoframe[tfitmp];
    attr_slicesbuffer.array[si] = __SSAT(s, 28) >> attr_slicesbuffer.GAIN;
    tfitmp++;
    si++;
    tfitmp %= FRAME_SIZE * 2;
  }
}

/*  Apply an half Hanning window on the end of the recorded sample (2 frames)
 *  Hanning is full range (input in range 0..MAX_INT).
 *  Start on the middle of the hanning window and finish on the end the hanning
 * window.
 */
void fadeout(uint32_t cuepoint) {
  /* MAX_INT / 2 => hanning window is full range (input in range 0..MAX_INT).
   *  Start on the middle of the hanning window. */
  uint32_t phase = HANMID;
  int32_t r;
  int32_t s;
  for (int i = cuepoint - (2 * FRAME_SIZE); i < cuepoint; i++) {
    HANNING2TINTERP(phase, r)
    s = ___SMMUL(attr_slicesbuffer.array[i], r >> 4)
        << 5; // see "insert_twoframe"
    attr_slicesbuffer.array[i] = __SSAT(s, 28) >> attr_slicesbuffer.GAIN;
    phase += (HANINC / 2); // HANINC is a FRAMESIZE increment. Fadeout apply a
                           // fadeout on 2 frames.
  }

  /* Store cuepoint */
  if (sii < attr_slicesindex.LENGTH) {
    attr_slicesindex.array[0] = sii;
    attr_slicesindex.array[sii++] = cuepoint;
  }
}

void detection() {
  float peakenvelope_tmp = peakenvelope;
  power_decibel = log(energy * 15625000 + 1) * 4.34294482f;
  // 0.015625 = 1/64 for compute the mean of sum of squares (64 samples
  // (FRAME_SIZE)) P0 = 0,000000001 is the power ref, then 10*log10(P/P0) <=>
  // 10*log10(energy/64 * 1000000000) log10(x) = ln(x)/ln(10), then 10*log10(x)
  // = ln(x)*10/ln(10) = ln(x)*4,34294482
  delta = power_decibel - peakenvelope_tmp;

  if ((power_decibel > power_db_threshold) && (delta > delta_power_db) &&
      !(timer > 0)) {
    if (confmode)
      LogTextMessage("power_db / delta_power_db : %f / %f", power_decibel,
                     delta);
    trig = 1;
    if (!(detect)) {
      insert_twoframe();
      detect = 1;
    } else {
      fadeout(zerocrosspoint);
    }
    timer = INITTIMER; // To avoid closed detections
  }
  peakenvelope_tmp = radius * peakenvelope_tmp;
  if (power_decibel > peakenvelope_tmp)
    peakenvelope_tmp = power_decibel;

  // Silence detection
  if (detect && !(timer > 0) && (peakenvelope_tmp < silence_db_threshold)) {
    detect = 0;
    fadeout(si);
  }
  peakenvelope = peakenvelope_tmp;
}

attr_conf

    radius = exp(((-1000.f / 48000.f) * ((float)(BUFSIZE * NB_CHUNK_FRAME))) /
                 timeconstant);

power_db_threshold = (float)param_power__db__threshold;
delta_power_db = (float)param_delta__power__db;
silence_db_threshold = (float)param_silence__db__threshold;

/****************/
/* Record logic */
/****************/

float s = 0.f;
float prev_s = 0.f;
static uint32_t zerocrosspoint_tmp = 0;
trig = 0;

if (param_delete__last > 0 && !preset && (sii > 1)) {
  preset = 1;
  si = 0;
  sii = attr_slicesindex.array[0];
  attr_slicesindex.array[0] = (sii - 1);
} else if (!(param_delete__last > 0)) {
  preset = 0;
}

if (timer > 0)
  timer--;

for (int i = 0; i < BUFSIZE; i++) {
  s = q_to_float(inlet_in[i], 27);
  if (detect) {
    if (crosscheck && (prev_s * s < 0)) {
      zerocrosspoint_tmp = si;
      crosscheck = 0;
    }
    attr_slicesbuffer.array[si] =
        __SSAT(inlet_in[i], 28) >> attr_slicesbuffer.GAIN;
    si++;
  } else {
    twoframe[tfi] = inlet_in[i];
    tfi++;
  }
  energy = s * s;
  prev_s = s;
}

tfi %= 2 * FRAME_SIZE;
if (curchunk == NB_CHUNK_FRAME - 1) {
  crosscheck = 1;
  detection(); // Attack and decay to zero detection
  zerocrosspoint = zerocrosspoint_tmp;
  energy = 0;
}
curchunk++;
curchunk %= NB_CHUNK_FRAME;

/************************/
/* Displays and outputs */
/************************/
disp_record = detect;
disp_current_slice_index = (sii - 1);
outlet_record = detect;
