static const int16_t iN = attr_wood;

int32_t au[iN];
int32_t au1[iN];
int32_t au2[iN];
int32_t rc[iN];
int32_t rcFull[iN];

int32_t *u;
int32_t *u1;
int32_t *u2;

int32_t s0;
int32_t s1;
int32_t s2;

int32_t iu0 = 0.5 * 0x7FFFFFFF;

int32_t irp_int;

bool trigged;

int32_t decay;

int32_t ran[44] = {2,  5,  16, 8,  5,  8,  21, 14, 16, 27, 32, 3,  7,  13, 25,
                   7,  28, 3,  30, 12, 13, 14, 2,  5,  16, 8,  5,  8,  21, 14,
                   16, 27, 32, 3,  7,  13, 25, 7,  28, 3,  30, 12, 13, 14};

int32_t k;

int32_t SR = 48000; // sample rate (Hz)

float K = 1;

float muu = 0.5; //% scheme free parameter
float rp = 0.5;  //% position of readout (0-1)

//%%%%%% end global parameters

//%%%%%% begin derived parameters

float kk = 1.f / SR; //       % time step
float hh = sqrtf(K * kk / muu);
int32_t h = (1.f / iN) * 0x7FFFFFFF;
int32_t mu = muu * 0x7FFFFFFF;

int32_t ctr = 1 << 26; // center location of excitation (0-1)

int32_t wid = 1 << 24; // width of excitation

int32_t iv0 = 0; // maximum initial velocity

k = kk * 0x7FFFFFFF;
irp_int = (rp * iN);

u = au;
u1 = au1;
u2 = au2;

trigged = 0;

decay = 12;

// LogTextMessage("%.f, %.f, %.f",float(s0)/0x7FFFFFF, float(s1)/0x7FFFFFF,
// float(s2)/0x7FFFFFF);				                        	//
// rounded grid index for readout

//%%%%%% create raised cosine

for (int i = 0; i < iN; i++) {
  int32_t pos = i * (h >> 4);
  int32_t dist = ctr - pos;
  int32_t absdist;
  dist > 0 ? absdist = dist : absdist = -dist;
  if (absdist <= wid >> 1) {
    int32_t arg = dist << 8;
    int32_t r;
    SINE2TINTERP(arg + (1 << 30), r);
    rc[i] = 0x40000000 + (r >> 1);
    // LogTextMessage("%.2f",(float)rc[i]/float(0x7FFFFFFF));
  }
  // LogTextMessage("%.10f",float(dist)/float(1<<27));
  // LogTextMessage("%d %d\n",i,pos);
}
wid = 0x3FFFFFF;
for (int i = 0; i < iN; i++) {
  int32_t pos = i * (h >> 4);
  int32_t dist = ctr - pos;
  int32_t absdist;
  dist > 0 ? absdist = dist : absdist = -dist;
  if (absdist <= wid >> 1) {
    int32_t arg = dist << 8;
    int32_t r;
    SINE2TINTERP(arg + (1 << 30), r);
    rcFull[i] = 0x40000000 + (r >> 1);
    // LogTextMessage("%.2f",(float)rc[i]/float(0x7FFFFFFF));
  }
  // LogTextMessage("%.10f",float(dist)/float(1<<27));
  // LogTextMessage("%d %d\n",i,pos);
}

int32_t mu = inlet_mu << 4;

s0 = (2 << 27) - 3 * (___SMMUL(mu, mu) >> 2);
s1 = ___SMMUL(mu, mu) >> 7;
s2 = -___SMMUL(mu, mu) >> 3;

int32_t offset = ((inlet_offset - 0x3FFFFFF) * iN) / 0x7FFFFFF;

if (inlet_trig == 1 && trigged == 0) {

  // int32_t v = ___SMMUL(inlet_velo,k)<<5;
  // LogTextMessage("%08x",v);
  // offset=0;
  // iu0=0;
  for (int i = 0; i < iN; i++) {
    if (i + offset > -1 && i + offset < iN) {
      u2[i] = ___SMMUL(iu0, rc[i + offset]);
      u1[i] = ___SMMUL(iu0, rc[i + offset]);

      //[i] = ___SMMUL(iu0,___SMMUL(rcFull[i+offset],ran[i+2]<<22));
      // u1[i] = ___SMMUL(iu0,___SMMUL(rcFull[i+offset],ran[i+2]<<22));
    }

    else {
      u2[i] = 0;
      u1[i] = 0;
    }
  }
  trigged = 1;
  decay = inlet_decay >> 23;
}
if (inlet_trig == 0) {
  trigged = 0;
}

for (int i = 2; i < iN; i++) {
  u[i] = -u2[i] + ((___SMMLA(s0, u1[i],
                             ___SMMLA(s1, u1[i - 1] + u1[i + 1],
                                      ___SMMUL(s2, u1[i - 2] + u1[i + 2]))))
                   << 5);
  u[i] -= u[i] >> decay;
}

outlet_o1 = u[irp_int] >> 4;

u1[irp_int] += inlet_input << 1;
u2 = u1;
u1 = u;
u = u2;
s0 = (2 << 27) - 3 * (___SMMUL(mu, mu) >> 2);
s1 = ___SMMUL(mu, mu) >> 7;
s2 = -___SMMUL(mu, mu) >> 3;
