f32ms
16 bipolar fractional controls fed into a muxer. Use input to select which one of the 16 fractional values to output. Nr output shows which integer value is currently selected.
Inlets
int32.positive s
Outlets
int32 nr
frac32 o
Parameters
int32 sel
frac32.s.map 1
frac32.s.map 2
frac32.s.map 3
frac32.s.map 4
frac32.s.map 5
frac32.s.map 6
frac32.s.map 7
frac32.s.map 8
frac32.s.map 9
frac32.s.map 10
frac32.s.map 11
frac32.s.map 12
frac32.s.map 13
frac32.s.map 14
frac32.s.map 15
frac32.s.map 16
frac32.s.map 17
frac32.s.map 18
frac32.s.map 19
frac32.s.map 20
frac32.s.map 21
frac32.s.map 22
frac32.s.map 23
frac32.s.map 24
frac32.s.map 25
frac32.s.map 26
frac32.s.map 27
frac32.s.map 28
frac32.s.map 29
frac32.s.map 30
frac32.s.map 31
frac32.s.map 32
switch (inlet_s + param_sel > 0 ? inlet_s + param_sel - 1 : 0) {
case 0:
outlet_o = param_1;
break;
case 1:
outlet_o = param_2;
break;
case 2:
outlet_o = param_3;
break;
case 3:
outlet_o = param_4;
break;
case 4:
outlet_o = param_5;
break;
case 5:
outlet_o = param_6;
break;
case 6:
outlet_o = param_7;
break;
case 7:
outlet_o = param_8;
break;
case 8:
outlet_o = param_9;
break;
case 9:
outlet_o = param_10;
break;
case 10:
outlet_o = param_11;
break;
case 11:
outlet_o = param_12;
break;
case 12:
outlet_o = param_13;
break;
case 13:
outlet_o = param_14;
break;
case 14:
outlet_o = param_15;
break;
case 15:
outlet_o = param_16;
break;
case 16:
outlet_o = param_17;
break;
case 17:
outlet_o = param_18;
break;
case 18:
outlet_o = param_19;
break;
case 19:
outlet_o = param_20;
break;
case 20:
outlet_o = param_21;
break;
case 21:
outlet_o = param_22;
break;
case 22:
outlet_o = param_23;
break;
case 23:
outlet_o = param_24;
break;
case 24:
outlet_o = param_25;
break;
case 25:
outlet_o = param_26;
break;
case 26:
outlet_o = param_27;
break;
case 27:
outlet_o = param_28;
break;
case 28:
outlet_o = param_29;
break;
case 29:
outlet_o = param_30;
break;
case 30:
outlet_o = param_31;
break;
case 31:
outlet_o = param_32;
break;
default:
outlet_o = param_32;
break;
}
outlet_nr = inlet_s + param_sel;
