// 1//
#if attr_location == 0
#define LOCATION
#else
#define LOCATION __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW = (attr_buffsize);
static const uint32_t LENGTH = (1 << attr_buffsize);
static const uint32_t LENGTHMASK = ((1 << attr_buffsize) - 1);

int32_t *delayline;
int wptr;

// 2//
#if attr_location == 0
#define LOCATION2
#else
#define LOCATION2 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW2 = (attr_buffsize);
static const uint32_t LENGTH2 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK2 = ((1 << attr_buffsize) - 1);

int32_t *delayline2;
int wptr2;

// 3//
#if attr_location == 0
#define LOCATION3
#else
#define LOCATION3 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW3 = (attr_buffsize);
static const uint32_t LENGTH3 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK3 = ((1 << attr_buffsize) - 1);

int32_t *delayline3;
int wptr3;

// 4//
#if attr_location == 0
#define LOCATION4
#else
#define LOCATION4 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW4 = (attr_buffsize);
static const uint32_t LENGTH4 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK4 = ((1 << attr_buffsize) - 1);

int32_t *delayline4;
int wptr4;

// 5//
#if attr_location == 0
#define LOCATION5
#else
#define LOCATION5 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW5 = (attr_buffsize);
static const uint32_t LENGTH5 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK5 = ((1 << attr_buffsize) - 1);

int32_t *delayline5;
int wptr5;

// 6//
#if attr_location == 0
#define LOCATION6
#else
#define LOCATION6 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW6 = (attr_buffsize);
static const uint32_t LENGTH6 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK6 = ((1 << attr_buffsize) - 1);

int32_t *delayline6;
int wptr6;

// 7//
#if attr_location == 0
#define LOCATION7
#else
#define LOCATION7 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW7 = (attr_buffsize);
static const uint32_t LENGTH7 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK7 = ((1 << attr_buffsize) - 1);

int32_t *delayline7;
int wptr7;

// 8//
#if attr_location == 0
#define LOCATION8
#else
#define LOCATION8 __attribute__((section(".sdram")))
#endif
static const uint32_t LENGTHPOW8 = (attr_buffsize);
static const uint32_t LENGTH8 = (1 << attr_buffsize);
static const uint32_t LENGTHMASK8 = ((1 << attr_buffsize) - 1);

int32_t *delayline8;
int wptr8;

// Hvad med de der parent og poly index??? //
// 1 //
static int32_t array_[attr_poly][LENGTH] LOCATION;
delayline = &array_[parent->polyIndex][0];

for (int i = 0; i < LENGTH; i++)
  delayline[i] = 0;
wptr = 0;

// 2 //
static int32_t array2_[attr_poly][LENGTH2] LOCATION2;
delayline2 = &array2_[parent->polyIndex][0];

for (int i2 = 0; i2 < LENGTH2; i2++)
  delayline2[i2] = 0;
wptr2 = 0;

// 3 //
static int32_t array3_[attr_poly][LENGTH3] LOCATION3;
delayline3 = &array3_[parent->polyIndex][0];

for (int i3 = 0; i3 < LENGTH3; i3++)
  delayline3[i3] = 0;
wptr3 = 0;

// 4 //
static int32_t array4_[attr_poly][LENGTH4] LOCATION4;
delayline4 = &array4_[parent->polyIndex][0];

for (int i4 = 0; i4 < LENGTH4; i4++)
  delayline4[i4] = 0;
wptr4 = 0;

// 5 //
static int32_t array5_[attr_poly][LENGTH5] LOCATION5;
delayline5 = &array5_[parent->polyIndex][0];

for (int i5 = 0; i5 < LENGTH5; i5++)
  delayline5[i5] = 0;
wptr5 = 0;

// 6 //
static int32_t array6_[attr_poly][LENGTH6] LOCATION6;
delayline6 = &array6_[parent->polyIndex][0];

for (int i6 = 0; i6 < LENGTH6; i6++)
  delayline6[i6] = 0;
wptr6 = 0;

// 7 //
static int32_t array7_[attr_poly][LENGTH6] LOCATION7;
delayline7 = &array7_[parent->polyIndex][0];

for (int i7 = 0; i7 < LENGTH7; i7++)
  delayline7[i7] = 0;
wptr7 = 0;

// 8 //
static int32_t array8_[attr_poly][LENGTH8] LOCATION8;
delayline8 = &array8_[parent->polyIndex][0];

for (int i8 = 0; i8 < LENGTH6; i8++)
  delayline8[i8] = 0;
wptr8 = 0;

// 1 //
int32_t g2 = inlet_gain << 3;

int32_t time = ___SMMUL(inlet_time, inlet_timemod) + inlet_time;
int32_t readOffset_ls8 = ___SMMUL(LENGTH << 10, time << 3);

if (readOffset_ls8 < (8 << 8))
  readOffset_ls8 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint = readOffset_ls8 >> 8; // integral part of delay time
int32_t rfrac =
    readOffset_ls8 & 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x2 = (rfrac * rfrac); // x^2 in Q16 notation
// in Q16 notation
int32_t c1 = (1 << 16) + (x2 >> 1) - (rfrac << 7) - (rfrac << 8);
int32_t c2 = -x2 + (rfrac << 9);
int32_t c3 = (x2 >> 1) - (rfrac << 7);
#endif

// 2 //
int32_t g22 = inlet_gain2 << 3;

int32_t time2 = ___SMMUL(inlet_time2, inlet_timemod2) + inlet_time2;
int32_t readOffset_ls82 = ___SMMUL(LENGTH2 << 10, time2 << 3);

if (readOffset_ls82 < (8 << 8))
  readOffset_ls82 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint2 = readOffset_ls82 >> 8; // integral part of delay time
int32_t rfrac2 = readOffset_ls82 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x22 = (rfrac2 * rfrac2); // x^2 in Q16 notation
// in Q16 notation
int32_t c12 = (1 << 16) + (x22 >> 1) - (rfrac2 << 7) - (rfrac2 << 8);
int32_t c22 = -x22 + (rfrac2 << 9);
int32_t c32 = (x22 >> 1) - (rfrac2 << 7);
#endif

// 3 //
int32_t g23 = inlet_gain3 << 3;

int32_t time3 = ___SMMUL(inlet_time3, inlet_timemod3) + inlet_time3;
int32_t readOffset_ls83 = ___SMMUL(LENGTH3 << 10, time3 << 3);

if (readOffset_ls83 < (8 << 8))
  readOffset_ls83 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint3 = readOffset_ls83 >> 8; // integral part of delay time
int32_t rfrac3 = readOffset_ls83 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x3 = (rfrac3 * rfrac3); // x^2 in Q16 notation
// in Q16 notation
int32_t c13 = (1 << 16) + (x3 >> 1) - (rfrac3 << 7) - (rfrac3 << 8);
int32_t c23 = -x3 + (rfrac3 << 9);
int32_t c33 = (x3 >> 1) - (rfrac3 << 7);
#endif

// 4 //
int32_t g24 = inlet_gain4 << 3;

int32_t time4 = ___SMMUL(inlet_time4, inlet_timemod4) + inlet_time4;
int32_t readOffset_ls84 = ___SMMUL(LENGTH4 << 10, time4 << 3);

if (readOffset_ls84 < (8 << 8))
  readOffset_ls84 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint4 = readOffset_ls84 >> 8; // integral part of delay time
int32_t rfrac4 = readOffset_ls84 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x4 = (rfrac4 * rfrac4); // x^2 in Q16 notation
// in Q16 notation
int32_t c14 = (1 << 16) + (x4 >> 1) - (rfrac4 << 7) - (rfrac4 << 8);
int32_t c24 = -x4 + (rfrac4 << 9);
int32_t c34 = (x4 >> 1) - (rfrac4 << 7);
#endif

// 5 //
int32_t g25 = inlet_gain5 << 3;

int32_t time5 = ___SMMUL(inlet_time5, inlet_timemod5) + inlet_time5;
int32_t readOffset_ls85 = ___SMMUL(LENGTH5 << 10, time5 << 3);

if (readOffset_ls85 < (8 << 8))
  readOffset_ls85 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint5 = readOffset_ls85 >> 8; // integral part of delay time
int32_t rfrac5 = readOffset_ls85 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x5 = (rfrac5 * rfrac5); // x^2 in Q16 notation
// in Q16 notation
int32_t c15 = (1 << 16) + (x5 >> 1) - (rfrac5 << 7) - (rfrac5 << 8);
int32_t c25 = -x5 + (rfrac5 << 9);
int32_t c35 = (x5 >> 1) - (rfrac5 << 7);
#endif

// 6 //
int32_t g26 = inlet_gain6 << 3;

int32_t time6 = ___SMMUL(inlet_time6, inlet_timemod6) + inlet_time6;
int32_t readOffset_ls86 = ___SMMUL(LENGTH6 << 10, time6 << 3);

if (readOffset_ls86 < (8 << 8))
  readOffset_ls86 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint6 = readOffset_ls86 >> 8; // integral part of delay time
int32_t rfrac6 = readOffset_ls86 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x6 = (rfrac6 * rfrac6); // x^2 in Q16 notation
// in Q16 notation
int32_t c16 = (1 << 16) + (x6 >> 1) - (rfrac6 << 7) - (rfrac6 << 8);
int32_t c26 = -x6 + (rfrac6 << 9);
int32_t c36 = (x6 >> 1) - (rfrac6 << 7);
#endif

// 7 //
int32_t g27 = inlet_gain7 << 3;

int32_t time7 = ___SMMUL(inlet_time7, inlet_timemod7) + inlet_time7;
int32_t readOffset_ls87 = ___SMMUL(LENGTH7 << 10, time7 << 3);

if (readOffset_ls87 < (8 << 8))
  readOffset_ls87 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint7 = readOffset_ls87 >> 8; // integral part of delay time
int32_t rfrac7 = readOffset_ls87 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x7 = (rfrac7 * rfrac7); // x^2 in Q16 notation
// in Q16 notation
int32_t c17 = (1 << 16) + (x7 >> 1) - (rfrac7 << 7) - (rfrac7 << 8);
int32_t c27 = -x7 + (rfrac7 << 9);
int32_t c37 = (x7 >> 1) - (rfrac7 << 7);
#endif

// 8 //
int32_t g28 = inlet_gain8 << 3;

int32_t time8 = ___SMMUL(inlet_time8, inlet_timemod8) + inlet_time8;
int32_t readOffset_ls88 = ___SMMUL(LENGTH8 << 10, time8 << 3);

if (readOffset_ls88 < (8 << 8))
  readOffset_ls88 = (8 << 8); // never less delay than 8 samples

#if attr_interpol > 0
int32_t rint8 = readOffset_ls88 >> 8; // integral part of delay time
int32_t rfrac8 = readOffset_ls88 &
                 0x000000FF; // fractional part of delay time in Q8 notation
#endif

// pre-calculate coefficients for 3pt interpolation
#if attr_interpol == 2

int32_t x8 = (rfrac8 * rfrac8); // x^2 in Q16 notation
// in Q16 notation
int32_t c18 = (1 << 16) + (x8 >> 1) - (rfrac8 << 7) - (rfrac8 << 8);
int32_t c28 = -x8 + (rfrac8 << 9);
int32_t c38 = (x8 >> 1) - (rfrac8 << 7);
#endif

// 1 //

// no interpolation
#if attr_interpol == 0
int32_t rptr = wptr - (readOffset_ls8 >> 8);
int32_t dout = delayline[rptr & LENGTHMASK];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr1 = wptr - rint;
int32_t rptr2 = rptr1 + 1;
int32_t dout1 = delayline[rptr2 & LENGTHMASK] >> 1;
int32_t dout2 = delayline[rptr1 & LENGTHMASK] >> 1;
int32_t dout = ___SMMLA(rfrac << 23, (dout2 - dout1) << 1, dout1) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr1 = wptr - rint;
int32_t rptr2 = rptr1 + 1;
int32_t rptr3 = rptr1 + 2;

int32_t dout1 = delayline[rptr3 & LENGTHMASK];
int32_t dout2 = delayline[rptr2 & LENGTHMASK];
int32_t dout3 = delayline[rptr1 & LENGTHMASK];
int32_t douttmp1 = ___SMMUL(dout1, c1 << 14);
int32_t douttmp2 = ___SMMLA(dout2, c2 << 14, douttmp1);
int32_t dout = ___SMMLA(dout3, c3 << 14, douttmp2) << 2;
#endif

int32_t din = ___SMMLA(g2, dout, inlet_in >> 2) << 1;
delayline[wptr] = din;
outlet_out = ___SMMLS(g2, din, dout >> 1) << 2;
wptr = (wptr + 1) & LENGTHMASK;

// 2 //

// no interpolation
#if attr_interpol == 0
int32_t rptr2 = wptr2 - (readOffset_ls82 >> 8);
int32_t dout222 = delayline2[rptr2 & LENGTHMASK2];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr12 = wptr2 - rint2;
int32_t rptr22 = rptr12 + 1;
int32_t dout12 = delayline2[rptr22 & LENGTHMASK2] >> 1;
int32_t dout22 = delayline2[rptr12 & LENGTHMASK2] >> 1;
int32_t dout222 = ___SMMLA(rfrac2 << 23, (dout22 - dout12) << 1, dout12) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr12 = wptr2 - rint2;
int32_t rptr22 = rptr12 + 1;
int32_t rptr32 = rptr12 + 2;

int32_t dout12 = delayline2[rptr32 & LENGTHMASK2];
int32_t dout22 = delayline2[rptr22 & LENGTHMASK2];
int32_t dout32 = delayline2[rptr12 & LENGTHMASK2];
int32_t douttmp12 = ___SMMUL(dout12, c12 << 14);
int32_t douttmp22 = ___SMMLA(dout22, c22 << 14, douttmp12);
int32_t dout222 = ___SMMLA(dout32, c32 << 14, douttmp22) << 2;
#endif

int32_t din2 = ___SMMLA(g22, dout222, inlet_two >> 2) << 1;
delayline2[wptr2] = din2;
outlet_two = ___SMMLS(g22, din2, dout222 >> 1) << 2;
wptr2 = (wptr2 + 1) & LENGTHMASK2;

// 3 //

// no interpolation
#if attr_interpol == 0
int32_t rptr3 = wptr3 - (readOffset_ls83 >> 8);
int32_t dout333 = delayline3[rptr3 & LENGTHMASK3];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr13 = wptr3 - rint3;
int32_t rptr23 = rptr13 + 1;
int32_t dout13 = delayline3[rptr23 & LENGTHMASK3] >> 1;
int32_t dout23 = delayline3[rptr13 & LENGTHMASK3] >> 1;
int32_t dout333 = ___SMMLA(rfrac3 << 23, (dout23 - dout13) << 1, dout13) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr13 = wptr3 - rint3;
int32_t rptr23 = rptr13 + 1;
int32_t rptr33 = rptr13 + 2;

int32_t dout13 = delayline3[rptr33 & LENGTHMASK3];
int32_t dout23 = delayline3[rptr23 & LENGTHMASK3];
int32_t dout33 = delayline3[rptr13 & LENGTHMASK3];
int32_t douttmp13 = ___SMMUL(dout13, c13 << 14);
int32_t douttmp23 = ___SMMLA(dout23, c23 << 14, douttmp13);
int32_t dout333 = ___SMMLA(dout33, c33 << 14, douttmp23) << 2;
#endif

int32_t din3 = ___SMMLA(g23, dout333, inlet_three >> 2) << 1;
delayline3[wptr3] = din3;
outlet_three = ___SMMLS(g23, din3, dout333 >> 1) << 2;
wptr3 = (wptr3 + 1) & LENGTHMASK3;

// 4 //

// no interpolation
#if attr_interpol == 0
int32_t rptr4 = wptr4 - (readOffset_ls84 >> 8);
int32_t dout4 = delayline4[rptr4 & LENGTHMASK4];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr14 = wptr4 - rint4;
int32_t rptr24 = rptr14 + 1;
int32_t dout14 = delayline4[rptr24 & LENGTHMASK4] >> 1;
int32_t dout24 = delayline4[rptr14 & LENGTHMASK4] >> 1;
int32_t dout4 = ___SMMLA(rfrac4 << 23, (dout24 - dout14) << 1, dout14) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr14 = wptr4 - rint4;
int32_t rptr24 = rptr14 + 1;
int32_t rptr34 = rptr14 + 2;

int32_t dout14 = delayline4[rptr34 & LENGTHMASK4];
int32_t dout24 = delayline4[rptr24 & LENGTHMASK4];
int32_t dout34 = delayline4[rptr14 & LENGTHMASK4];
int32_t douttmp14 = ___SMMUL(dout14, c14 << 14);
int32_t douttmp24 = ___SMMLA(dout24, c24 << 14, douttmp14);
int32_t dout4 = ___SMMLA(dout34, c34 << 14, douttmp24) << 2;
#endif

int32_t din4 = ___SMMLA(g24, dout4, inlet_four >> 2) << 1;
delayline4[wptr4] = din4;
outlet_four = ___SMMLS(g24, din4, dout4 >> 1) << 2;
wptr4 = (wptr4 + 1) & LENGTHMASK4;

// 5 //

// no interpolation
#if attr_interpol == 0
int32_t rptr5 = wptr5 - (readOffset_ls85 >> 8);
int32_t dout5 = delayline5[rptr5 & LENGTHMASK5];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr15 = wptr5 - rint5;
int32_t rptr25 = rptr15 + 1;
int32_t dout15 = delayline5[rptr25 & LENGTHMASK5] >> 1;
int32_t dout25 = delayline5[rptr15 & LENGTHMASK5] >> 1;
int32_t dout5 = ___SMMLA(rfrac5 << 23, (dout25 - dout15) << 1, dout15) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr15 = wptr5 - rint5;
int32_t rptr25 = rptr15 + 1;
int32_t rptr35 = rptr15 + 2;

int32_t dout15 = delayline5[rptr35 & LENGTHMASK5];
int32_t dout25 = delayline5[rptr25 & LENGTHMASK5];
int32_t dout35 = delayline5[rptr15 & LENGTHMASK5];
int32_t douttmp15 = ___SMMUL(dout15, c15 << 14);
int32_t douttmp25 = ___SMMLA(dout25, c25 << 14, douttmp15);
int32_t dout5 = ___SMMLA(dout35, c35 << 14, douttmp25) << 2;
#endif

int32_t din5 = ___SMMLA(g25, dout5, inlet_five >> 2) << 1;
delayline5[wptr5] = din5;
outlet_five = ___SMMLS(g25, din5, dout5 >> 1) << 2;
wptr5 = (wptr5 + 1) & LENGTHMASK5;

// 6 //

// no interpolation
#if attr_interpol == 0
int32_t rptr6 = wptr6 - (readOffset_ls86 >> 8);
int32_t dout6 = delayline6[rptr6 & LENGTHMASK6];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr16 = wptr6 - rint6;
int32_t rptr26 = rptr16 + 1;
int32_t dout16 = delayline6[rptr26 & LENGTHMASK6] >> 1;
int32_t dout26 = delayline6[rptr16 & LENGTHMASK6] >> 1;
int32_t dout6 = ___SMMLA(rfrac6 << 23, (dout26 - dout16) << 1, dout16) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr16 = wptr6 - rint6;
int32_t rptr26 = rptr16 + 1;
int32_t rptr36 = rptr16 + 2;

int32_t dout16 = delayline6[rptr36 & LENGTHMASK6];
int32_t dout26 = delayline6[rptr26 & LENGTHMASK6];
int32_t dout36 = delayline6[rptr16 & LENGTHMASK6];
int32_t douttmp16 = ___SMMUL(dout16, c16 << 14);
int32_t douttmp26 = ___SMMLA(dout26, c26 << 14, douttmp16);
int32_t dout6 = ___SMMLA(dout36, c36 << 14, douttmp26) << 2;
#endif

int32_t din6 = ___SMMLA(g26, dout6, inlet_six >> 2) << 1;
delayline6[wptr6] = din6;
outlet_six = ___SMMLS(g26, din6, dout6 >> 1) << 2;
wptr6 = (wptr6 + 1) & LENGTHMASK6;

// 7 //

// no interpolation
#if attr_interpol == 0
int32_t rptr7 = wptr7 - (readOffset_ls87 >> 8);
int32_t dout7 = delayline7[rptr6 & LENGTHMASK7];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr17 = wptr7 - rint7;
int32_t rptr27 = rptr17 + 1;
int32_t dout17 = delayline7[rptr27 & LENGTHMASK7] >> 1;
int32_t dout27 = delayline7[rptr17 & LENGTHMASK7] >> 1;
int32_t dout7 = ___SMMLA(rfrac7 << 23, (dout27 - dout17) << 1, dout17) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr17 = wptr7 - rint7;
int32_t rptr27 = rptr17 + 1;
int32_t rptr37 = rptr17 + 2;

int32_t dout17 = delayline7[rptr37 & LENGTHMASK7];
int32_t dout27 = delayline7[rptr27 & LENGTHMASK7];
int32_t dout37 = delayline7[rptr17 & LENGTHMASK7];
int32_t douttmp17 = ___SMMUL(dout17, c17 << 14);
int32_t douttmp27 = ___SMMLA(dout27, c27 << 14, douttmp17);
int32_t dout7 = ___SMMLA(dout37, c37 << 14, douttmp27) << 2;
#endif

int32_t din7 = ___SMMLA(g27, dout7, inlet_seven >> 2) << 1;
delayline7[wptr7] = din7;
outlet_seven = ___SMMLS(g27, din7, dout7 >> 1) << 2;
wptr7 = (wptr7 + 1) & LENGTHMASK7;

// 8 //

// no interpolation
#if attr_interpol == 0
int32_t rptr8 = wptr8 - (readOffset_ls88 >> 8);
int32_t dout8 = delayline8[rptr6 & LENGTHMASK8];
// linear (2pt) interpolation
#elif attr_interpol == 1
int32_t rptr18 = wptr8 - rint8;
int32_t rptr28 = rptr18 + 1;
int32_t dout18 = delayline8[rptr28 & LENGTHMASK8] >> 1;
int32_t dout28 = delayline8[rptr18 & LENGTHMASK8] >> 1;
int32_t dout8 = ___SMMLA(rfrac8 << 23, (dout28 - dout18) << 1, dout18) << 1;
// qubic (3pt) interpolation
#elif attr_interpol == 2
int32_t rptr18 = wptr8 - rint8;
int32_t rptr28 = rptr18 + 1;
int32_t rptr38 = rptr18 + 2;

int32_t dout18 = delayline8[rptr38 & LENGTHMASK8];
int32_t dout28 = delayline8[rptr28 & LENGTHMASK8];
int32_t dout38 = delayline8[rptr18 & LENGTHMASK8];
int32_t douttmp18 = ___SMMUL(dout18, c18 << 14);
int32_t douttmp28 = ___SMMLA(dout28, c28 << 14, douttmp18);
int32_t dout8 = ___SMMLA(dout38, c38 << 14, douttmp28) << 2;
#endif

int32_t din8 = ___SMMLA(g28, dout8, inlet_eight >> 2) << 1;
delayline8[wptr8] = din8;
outlet_eight = ___SMMLS(g28, din8, dout8 >> 1) << 2;
wptr8 = (wptr8 + 1) & LENGTHMASK8;
