// From delay write sdram //
static const uint32_t LENGTHPOW1 = (attr_s);
static const uint32_t LENGTH1 = (1 << attr_s);
static const uint32_t LENGTHMASK1 = ((1 << attr_s) - 1);
int16_t *array1;
uint32_t writepos1;

int32_t vala;

int32_t FILTERa;
int32_t FILTERINVa;
int32_t CLEANPLUSINVERTEDFILTERa;
int32_t CLEANPLUSINVERTEDFILTERINVa;
int32_t STEP2a;

// From delay write sdram //
static const uint32_t LENGTHPOW = (attr_s);
static const uint32_t LENGTH = (1 << attr_s);
static const uint32_t LENGTHMASK = ((1 << attr_s) - 1);
int16_t *array;
uint32_t writepos;

int32_t val;

int32_t FILTER;
int32_t FILTERINV;
int32_t CLEANPLUSINVERTEDFILTER;
int32_t CLEANPLUSINVERTEDFILTERINV;
int32_t STEP2;

// Delay - THis one is different than the others //
// I put the allpase AFTER the delay //
int32_t ALLPASSS;
int32_t MIX;

// LFO //
uint32_t phase;
uint32_t old_reset;
__attribute__((always_inline)) __STATIC_INLINE int32_t ___ABS(int32_t op1) {
  int32_t result;
  __ASM volatile("movs  %0, %1\n"
                 "it    mi\n"
                 "rsbmi %0, %0, #0"
                 : "=r"(result)
                 : "r"(op1));
  return (result);
};

// From delay write sdram //
static int16_t _array1[attr_poly][1 << attr_s]
    __attribute__((section(".sdram")));
array1 = &_array1[parent->polyIndex][0];
int i1;
writepos1 = 0;
for (i1 = 0; i1 < LENGTH1; i1++)
  array1[i1] = 0;

// 6db lo pass //
vala = 0;

// From delay write sdram //
static int16_t _array[attr_poly][1 << attr_s]
    __attribute__((section(".sdram")));
array = &_array[parent->polyIndex][0];
int i;
writepos = 0;
for (i = 0; i < LENGTH; i++)
  array[i] = 0;

// 6db lo pass //
val = 0;

phase = 0;
old_reset = 0;

if (0 && !old_reset) {
  phase = 0;
} else {
  int32_t freq;
  MTOFEXTENDED(param_lfospeed + inlet_lfo, freq);
  phase += freq >> 2;
}
old_reset = 0;

int32_t saw;

saw = (phase >> 4) - (1 << 27);
int32_t ZERO = (1 << 27) - ___ABS(saw << 1);

saw = ((phase - 0x40000000) >> 4) - (1 << 27);
int32_t NINETY = (1 << 27) - ___ABS(saw << 1);

int32_t ZEROAMOUNT;
int32_t NINETYAMOUNT;
// on/off button + amount
if (param_lfoon) {
  ZEROAMOUNT = ___SMMUL(ZERO << 3, param_lfoam << 2);
  NINETYAMOUNT = ___SMMUL(NINETY << 3, param_lfoam << 2);
}

else {
  ZEROAMOUNT = 0;
  NINETYAMOUNT = 0;
}

// 6db lo pass //
int32_t fa;
MTOF(ZEROAMOUNT + param_freqa, fa);

// 6db lo pass //
int32_t f;
MTOF(NINETYAMOUNT + param_freqa + param_freqb, f);

int32_t ccompl = ((128 << 20) - param_mix);

int32_t FEEDINVERT = (param_feedinvert) ? -outlet_out : outlet_out;
int32_t FEEDAMOUNT = ___SMMUL(FEEDINVERT << 3, param_feedback << 2);
int32_t FEEDLIMIT =
    ___SMMUL(FEEDAMOUNT << 3, (int32_t)(54.00f * (1 << 21)) << 2);

// 6db lo pass //
vala = ___SMMLA(((inlet_in + FEEDLIMIT) - vala) << 1, fa, vala);
FILTERa = vala;

FILTERINVa = -FILTERa;
CLEANPLUSINVERTEDFILTERa = (inlet_in + FEEDLIMIT) + FILTERINVa;
CLEANPLUSINVERTEDFILTERINVa = -CLEANPLUSINVERTEDFILTERa;
STEP2a = FILTERa + CLEANPLUSINVERTEDFILTERINVa;

// From delay write sdram //
writepos1 = (writepos1 + 1) & LENGTHMASK1;
array1[writepos1] = __SSAT(STEP2a >> 14, 16);

int32_t TIMEMINIMUM1 =
    (param_timea + inlet_time > (int32_t)(02.00f * (1 << 21)))
        ? param_timea + inlet_time
        : (int32_t)(02.00f * (1 << 21));
int32_t TIME1LIMIT =
    ___SMMUL(TIMEMINIMUM1 << 3, (int32_t)(08.00f * (1 << 21)) << 2);

// delay/read interp //
uint32_t tmp_d1 = __USAT(TIME1LIMIT, 27);
uint32_t tmp_di1 =
    writepos1 - (tmp_d1 >> (27 - LENGTHPOW1)); //- BUFSIZE + buffer_index -1//
uint32_t tmp_w11 = (tmp_d1 << (LENGTHPOW1 + 3)) & 0x3FFFFFFF;
uint32_t tmp_w21 = (1 << 30) - tmp_w11;
int32_t tmp_a11 = array1[tmp_di1 & LENGTHMASK1] << 16;
int32_t tmp_a21 = array1[(tmp_di1 + 1) & LENGTHMASK1] << 16;
int32_t tmp_r1 = ___SMMUL(tmp_a11, tmp_w11);
tmp_r1 = ___SMMLA(tmp_a21, tmp_w21, tmp_r1);
int32_t AP1 = tmp_r1;

// 6db lo pass //
val = ___SMMLA((AP1 - val) << 1, f, val);
FILTER = val;

FILTERINV = -FILTER;
CLEANPLUSINVERTEDFILTER = AP1 + FILTERINV;
CLEANPLUSINVERTEDFILTERINV = -CLEANPLUSINVERTEDFILTER;
STEP2 = FILTER + CLEANPLUSINVERTEDFILTERINV;

// From delay write sdram //
writepos = (writepos + 1) & LENGTHMASK;
array[writepos] = __SSAT(STEP2 >> 14, 16);

int32_t TIMEMINIMUM2 =
    (param_timeb + inlet_time > (int32_t)(02.00f * (1 << 21)))
        ? param_timeb + inlet_time
        : (int32_t)(02.00f * (1 << 21));
int32_t TIME2LIMIT =
    ___SMMUL(TIMEMINIMUM2 << 3, (int32_t)(08.00f * (1 << 21)) << 2);

// delay/read interp //
uint32_t tmp_d = __USAT(TIME2LIMIT, 27);
uint32_t tmp_di =
    writepos - (tmp_d >> (27 - LENGTHPOW)); //- BUFSIZE + buffer_index -1//
uint32_t tmp_w1 = (tmp_d << (LENGTHPOW + 3)) & 0x3FFFFFFF;
uint32_t tmp_w2 = (1 << 30) - tmp_w1;
int32_t tmp_a1 = array[tmp_di & LENGTHMASK] << 16;
int32_t tmp_a2 = array[(tmp_di + 1) & LENGTHMASK] << 16;
int32_t tmp_r = ___SMMUL(tmp_a1, tmp_w1);
tmp_r = ___SMMLA(tmp_a2, tmp_w2, tmp_r);
ALLPASSS = tmp_r;

{
  int64_t a = (int64_t)ALLPASSS * param_mix;
  a += (int64_t)inlet_in * ccompl;
  MIX = a >> 27;
}

outlet_out = (param_on) ? MIX : inlet_in;
