wave creator 16
wavetable creator.hit 'saw' 'sine' or 'square' to fill with an initial function. tables are accesible from the 'outside',if you reference the object's name with table/read and such.
Inlets
None
Outlets
None
Parameters
bool32.mom saw
bool32.mom sine
bool32.mom square
frac32.s.mapvsl b0
frac32.s.mapvsl b1
frac32.s.mapvsl b2
frac32.s.mapvsl b3
frac32.s.mapvsl b4
frac32.s.mapvsl b5
frac32.s.mapvsl b6
frac32.s.mapvsl b7
frac32.s.mapvsl b8
frac32.s.mapvsl b9
frac32.s.mapvsl b10
frac32.s.mapvsl b11
frac32.s.mapvsl b12
frac32.s.mapvsl b13
frac32.s.mapvsl b14
frac32.s.mapvsl b15
static const uint32_t LENGTHPOW = 4;
static const uint32_t LENGTH = 1 << 4;
static const uint32_t LENGTHMASK = (1 << 4) - 1;
static const uint32_t BITS = 32;
static const uint32_t GAIN = 0;
int32_t array[LENGTH];
bool trig;array[0] = param_b0;
array[1] = param_b1;
array[2] = param_b2;
array[3] = param_b3;
array[4] = param_b4;
array[5] = param_b5;
array[6] = param_b6;
array[7] = param_b7;
array[8] = param_b8;
array[9] = param_b9;
array[10] = param_b10;
array[11] = param_b11;
array[12] = param_b12;
array[13] = param_b13;
array[14] = param_b14;
array[15] = param_b15;
if (param_saw && (!trig)) {
trig = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b0],
-134217728.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b1],
-116322032.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b2],
-98426336.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b3],
-80530640.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b4],
-62634940.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b5],
-44739244.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b6],
-26843546.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b7],
-8947849.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b8],
8947849.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b9],
26843546.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b10],
44739244.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b11],
62634940.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b12],
80530640.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b13],
98426336.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b14],
116322032.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b15],
134217728.000, 0xFFFD);
}
if (param_sine && (!trig)) {
trig = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b0], 0.000,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b1],
51361464.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b2],
94904064.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b3],
123999224.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b4],
134217728.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b5],
124003984.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b6],
94912864.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b7],
51372956.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b8], 12436.267,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b9],
-51349976.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b10],
-94895272.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b11],
-123994464.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b12],
-134217728.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b13],
-124008744.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b14],
-94921656.000, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b15],
-51384444.000, 0xFFFD);
}
if (param_square && (!trig)) {
trig = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b0], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b1], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b2], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b3], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b4], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b5], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b6], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b7], 134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b8], -134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b9], -134217728,
0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b10],
-134217728, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b11],
-134217728, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b12],
-134217728, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b13],
-134217728, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b14],
-134217728, 0xFFFD);
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_b15],
-134217728, 0xFFFD);
}
if (!param_sine && !param_saw && !param_square)
trig = 0;
