matrix get
useful for polyphonic midi. noteOn issues a pulse whenever a note-on occurs, note returns the note number, with 'noteshift' added (or substracted) same for note off. hold is 1 if any keys are on hold. gate is true when velocity > 0
Inlets
None
Outlets
bool32 status of current note
bool32.pulse pulse on note-on
bool32.pulse pulse on note-off
int32 hold
int32.positive note number +/- 'noteshift'
int32.positive velocity
Declaration
uint8_t _note;
int8_t count;
uint8_t _velo;
uint8_t pren;
uint8_t prev;
uint8_t nstack[16] = {0};
uint8_t vstack[16] = {0};
uint8_t slength;
uint8_t sread;
uint8_t swrite;
uint8_t thin;
Init
slength = 0;
_note = 0;
_velo = 0;
Control Rate
outlet_padOn = 0;
outlet_padOff = 0;
if (!thin) {
thin = 2;
if (slength) {
_note = nstack[sread];
_velo = vstack[sread];
if (_velo) {
outlet_padOn = 1;
count++;
} else {
outlet_padOff = 1;
count--;
}
sread++;
sread = sread % 16;
slength--;
}
} else
thin--;
outlet_gate = bool(_velo);
outlet_hold = count;
outlet_pad = _note;
outlet_velo = _velo;
Midi Handler
if ((status == MIDI_NOTE_ON) && (data2)) {
if ((data1 >= 36) && (data1 <= 99)) {
nstack[swrite] = data1 - 36;
vstack[swrite] = data2;
slength++;
swrite++;
swrite = swrite % 16;
}
}
if (((status == MIDI_NOTE_ON) && (!data2)) || (status == MIDI_NOTE_OFF)) {
if ((data1 >= 36) && (data1 <= 99)) {
nstack[swrite] = data1 - 36;
vstack[swrite] = 0;
slength++;
swrite++;
swrite = swrite % 16;
}
} else if ((status == MIDI_CONTROL_CHANGE) && (data1 == MIDI_C_ALL_NOTES_OFF)) {
_velo = 0;
count = 0;
slength = 0;
}
