typedef struct {
  int32_t x1_old = 0; // old input
  int32_t x2_old = 0;
  int32_t x4_old = 0;
} waveshaper_state;

typedef struct {
  int32_t k = 0;
  int32_t k_c = 0;
} waveshaper_coefs;

static __attribute__((noinline)) void
waveshaper_set_coefs(waveshaper_coefs *wsc, int32_t coef) {
  (wsc->k) = coef;
  (wsc->k_c) = (1 << 27) - coef;
}

static __attribute__((noinline)) int32_t
waveshaper_process(waveshaper_state *wss, waveshaper_coefs *wsc,
                   int32_t input) {
  int32_t x1 = __SSAT(input, 28);          // saturating x to normal range
  int32_t x2 = ___SMMUL(x1 << 2, x1 << 3); // calculating x^2
  int32_t x3 = ___SMMUL(x2 << 2, x1 << 3); // calculating x^3
  int32_t x4 = ___SMMUL(x3 << 2, x1 << 3); // calculating x^4

  int32_t y = ___SMMLA(
      (wsc->k) << 2, x1 << 3,
      ___SMMUL((wsc->k_c) << 2, x3 << 3)); // kx + (1-k)x^3		[WAVESHAPER
                                           // FUNCTION] //non antialiased
  int32_t Y = ___SMMLA(
      (wsc->k) << 2, x2 << 2,
      ___SMMUL((wsc->k_c), x4 << 3)); // 0.5kx^2 + 0.25(1-k)x^4
                                      // [INTEGRATED FUNCTION] //antialiased
  // I had to recalculate old integral value in order to make the shape
  // parameter modulatable.
  int32_t Y_old =
      ___SMMLA((wsc->k) << 2, (wss->x2_old) << 2,
               ___SMMUL((wsc->k_c),
                        (wss->x4_old) << 3)); // 0.5kx^2 + 0.25(1-k)x^4
                                              // [INTEGRATED FUNCTION OLD VALUE]

  int32_t dx = x1 - (wss->x1_old); // new input - old input (used to calculate
                                   // the integral mean value)
  int32_t dx_abs = dx > 0 ? dx : -dx;
  float dY = (Y - Y_old);

  int32_t mean = 134217728.0f * ((dY) / (dx));

  (wss->x1_old) = x1;
  (wss->x2_old) = x2;
  (wss->x4_old) = x4;
  return (dx_abs > (1 << 6)
              ? mean
              : y); // we don't want to divide for an excessively small quantity
                    // (actually we simply discard that result)
}

int32_t y_old = 0; // this is used for internal feedback loop

waveshaper_state WS;
waveshaper_coefs WC;

int32_t filter_out = 0;
int32_t filter_state = 0;

int32_t shape;
int32_t feed = 0;
int32_t f = 0;

int32_t feed_increment = __SSAT(param_feed + inlet_feed, 28) - feed >> 4;

int32_t shape_increment = __SSAT(inlet_shape + param_shape, 28) - shape >> 4;

int32_t temp;
MTOFEXTENDED(param_pitch + inlet_pitch, temp);
int32_t f_incr = temp - f >> 4;

int32_t feed_abs =
    feed > 0 ? feed : -feed; // absolute value of the feedback parameter
int32_t input =
    param_tame
        ? ___SMMUL((1 << 27) - feed_abs << 2, inlet_in << 3)
        : inlet_in; // taming the feedback loop, in case the option is activated

waveshaper_set_coefs(&WC, ___SMMLA(shape << 4,
                                   shape > 0 ? (0x8000000) : (0x3FFFFFFE),
                                   1 << 27)); // binding the shape parameter
                                              // from -3 to 3/2 (magic range)

int32_t output = waveshaper_process(
    &WS, &WC,
    ___SMMLA(feed << 2, filter_out << 3,
             input)); // calculating the output of the waveshaper

feed += feed_increment; // interpolating inlets
f += f_incr;
shape += shape_increment;

filter_state = ___SMMLA(__SSAT((output - filter_state) << 1, 30), f,
                        filter_state); // processing 1 pole low pass filter

switch (param_filter_space_type) {
case 1:
  filter_out = filter_state;
  break; // no filter
case 2:
  filter_out = output - filter_state;
  break; // low pass
default:
  filter_out = output;
  break; // high pass
}

outlet_out = output;
outlet_filter = filter_out;
