int32_t val1;
int32_t val2;
int32_t val3;
int32_t temp;

int32_t prevMax;
int32_t prevBias;
int32_t prevMin;
int32_t prevDiffmax;
int32_t prevF;
int32_t prevG;
int32_t prevfb;
int32_t stepMax;
int32_t stepBias;
int32_t stepMin;
int32_t stepDiffmax;
int32_t stepF;
int32_t stepG;
int32_t stepfb;

if (param_max < param_min) {
  PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_min], param_max,
                     0xFFFD);
  PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_max], param_min,
                     0xFFFD);
}
if (param_LP < param_HP) {
  PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_HP], param_LP,
                     0xFFFD);
  PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_LP], param_HP,
                     0xFFFD);
}

int32_t Max = param_max + inlet_max;
int32_t Bias = param_bias + inlet_bias;
int32_t Min = param_min + inlet_min;
int32_t Diffmax = param_diffmax + inlet_diffmax;
Diffmax = Diffmax > 0 ? Diffmax : -Diffmax;
int32_t LP = param_LP + inlet_LP;
int32_t HP = param_HP + inlet_HP;
int32_t FD = __USAT(param_feedback + inlet_feed, 27);

int32_t F;
int32_t G;
MTOF(LP, F)
MTOF(HP, G)

stepMax = (Max - prevMax) >> 4;
stepBias = (Bias - prevBias) >> 4;
stepMin = (Min - prevMin) >> 4;
stepDiffmax = (Diffmax - prevDiffmax) >> 4;
stepF = (F - prevF) >> 4;
stepG = (G - prevG) >> 4;
stepfb = (FD - prevfb) >> 4;

int32_t max = prevMax;
int32_t bias = prevBias;
int32_t min = prevMin;
int32_t diffmax = prevDiffmax;
int32_t f = prevF;
int32_t g = prevG;
int32_t feedback = prevfb;

prevMax = Max;
prevBias = Bias;
prevMin = Min;
prevDiffmax = Diffmax;
prevF = F;
prevG = G;
prevfb = FD;

int32_t in = inlet_in + bias + ___SMMUL(feedback << 4, temp << 3);
in = in > max ? max : in;
in = in < min ? min : in;
int32_t DIFF = inlet_in - in;
DIFF = DIFF > diffmax ? diffmax : DIFF;
DIFF = DIFF < -diffmax ? -diffmax : DIFF;

val1 = ___SMMLA((DIFF - val1) << 1, f, val1);
val2 = ___SMMLA((val1 - val2) << 1, g, val2);
temp = val1 - val2 + in;
val3 = val3 + ((temp - val3) >> 10);
temp = temp - val3;
outlet_out = temp;

max += stepMax;
bias += stepBias;
min += stepMin;
diffmax += stepDiffmax;
f += stepF;
g += stepG;
feedback += stepfb;
