uint32_t Sub;
uint32_t Phase;
uint32_t Phrase;
int64_t ENV1;
int64_t ENV2;
int64_t ENV3;
int64_t envw;
int64_t envS;
int8_t stage1;
int8_t stage2;
int ntrig1;
int32_t val1;
int ntrig2;
int32_t val2;
int64_t ccomp;
int64_t decay;
int64_t wave;
int64_t pitwidth;
int64_t pithwidth;
int64_t rate;
int64_t srate;
int64_t dismix;
int32_t prev1;
int32_t step1;
int32_t ienv1;
int32_t prev2;
int32_t step2;
int32_t ienv2;
int32_t submix;

uint32_t Phose;
uint32_t R;
uint32_t H;
int32_t LFO;
int64_t MOd1;
int64_t MOd2;
int64_t MOd3;
int64_t MOd4;
int64_t MOd5;
int32_t dest;
int32_t Width;
int32_t sine;
int32_t slew;
int rateD;

Phase = 0;
Sub = 0;
ntrig1 = 0;
val1 = 0;
ntrig2 = 0;
val2 = 0;
Phose = 0;
R = 1;

int32_t freq;
MTOFEXTENDED(param_Pitch + inlet_pitch + (MOd1 >> 2), freq);

int32_t t;
MTOF((1 << 27) - param_Hit, t);

int32_t frec;
MTOFEXTENDED(param_EnvPos, frec)

pitwidth = frec - freq;
outlet_LFO = LFO;

int64_t Rate = ___SMMUL(param_rate << 3, param_rate << 2);
Rate = ___SMMUL(Rate << 3, Rate << 2);
Rate = ___SMMUL(Rate << 3, param_rate << 2) << 2;

ccomp = (1 << 31) - val1;
decay = param_d2 - param_d1;
decay = ___SMMUL(val1 >> 1, decay << 2);

// pitch envelope
if ((inlet_gate > 0) && !ntrig1) {
  ntrig1 = 1;
  stage1 = 1;
  Phase = 0;
  Sub = 0;
} else if (!(inlet_gate > 0)) {
  ntrig1 = 0;
}
if (stage1 == 0) {
  val1 = ___SMMUL(val1, param_d1 + decay + (1 << 17) + (1 << 15)) << 1;
} else {

  val1 = val1 + (t >> 2);
  if (val1 < 0) {
    val1 = 0x7FFFFFFF;
    stage1 = 0;
  }
}
ENV1 = val1 >> 4;

rateD = inlet_rateD > 0 ? inlet_rateD : 1;

// volume envelope
if ((inlet_gate > 0) && !ntrig2) {
  ntrig2 = 1;
  stage2 = 1;
} else if (!(inlet_gate > 0)) {
  ntrig2 = 0;
}
if (stage2 == 0) {
  val2 = ___SMMUL(val2, param_dV + (1 << 17) + (1 << 15)) << 1;
} else {

  val2 = val2 + (t >> 1);
  if (val2 < 0) {
    val2 = 0x7FFFFFFF;
    stage2 = 0;
  }
}
ENV2 = val2 >> 3;

{
  if (inlet_gate && !R) {
    Phose = param_start << 5;
    R = 1;
  } else {

    Phose += Rate * inlet_rateM / rateD;
  }
  if (!inlet_gate) {
    R = 0;
  }

  switch (param_waveform > 0 ? param_waveform : 0) {
  case 0:
    SINE2TINTERP(Phose, sine) LFO = (sine >> 5) + (1 << 26);
    break;
  case 1:
    LFO =
        (((Phose >> 4) - (1 << 27)) > (1 << 27) ? ((Phose >> 4) - (1 << 27))
                                                : -((Phose >> 4) - (1 << 27))) +
        (1 << 27);
    break;
  case 2:
    LFO = (Phose >> 5);
    break;
  case 3:
    LFO = (1 << 27) - (Phose >> 5);
    break;
  default:
    LFO = (((Phose >> 4) - (1 << 27)) > (1 << 27) ? (1 << 27) : 0);
    break;
  }
}
slew = slew + ___SMMUL((LFO - slew) << 3, Rate << 1);
dest = param_destination;
Width = param_width;
int32_t MODO = ___SMMUL(slew << 3, Width << 2);
switch (dest > 0 ? dest : 0) {
case 0:
  MOd1 = MODO;
  MOd2 = 0;
  MOd3 = 0;
  MOd4 = 0;
  MOd5 = 0;
  break;
case 1:
  MOd2 = MODO;
  MOd1 = 0;
  MOd3 = 0;
  MOd4 = 0;
  MOd5 = 0;
  break;
case 2:
  MOd3 = MODO;
  MOd1 = 0;
  MOd2 = 0;
  MOd4 = 0;
  MOd5 = 0;
  break;
case 3:
  MOd4 = MODO;
  MOd1 = 0;
  MOd2 = 0;
  MOd3 = 0;
  MOd5 = 0;
  break;
case 4:
  MOd5 = MODO;
  MOd1 = 0;
  MOd2 = 0;
  MOd3 = 0;
  MOd4 = 0;
  break;
default:
  MOd5 = MODO;
  MOd1 = 0;
  MOd2 = 0;
  MOd3 = 0;
  MOd4 = 0;
  break;
}

// extra volume envelope:
step1 = (inlet_env - prev1) >> 8;
ienv1 += step1;
prev1 = ienv1;

step2 = (((inlet_submix + param_submix + (MOd2 << 1)) >> 1) - prev2) >> 8;
submix += step2;
prev2 = submix;

envw = ___SMMUL((ENV1 + (ENV2 >> 6)) << 3, pitwidth << 2);
rate = freq + envw;
Phase += rate;
int32_t r;
int32_t s;

SINE2TINTERP(Phase << 1, r)
SINE2TINTERP(Phase + (1 < 30), s)

int32_t csub = (1 << 27) - param_submix;
int32_t oscmix = ___SMMUL(csub << 1, s) + ___SMMUL(submix << 1, r);
int32_t tscmix = oscmix;
dismix = __SSAT(___SMMUL(param_amp + (MOd3 << 3) + (inlet_amp << 3),
                         __SSAT(oscmix, 28) << 4)
                    << 1,
                28) >>
         2;
SINE2TINTERP((dismix + MOd5) << 5, s)
envS = ___SMMUL(((1 << 27) - ENV2) << 3, ienv1 << 2);
int64_t _1s = (s >> 5) + (tscmix);
int32_t MOdu = ___SMMUL(((1 << 27) - ENV2) << 3, MOd4 << 2);
wave = ___SMMUL(_1s, ENV2 << 3) + ___SMMUL(envS << 3, _1s) +
       ___SMMUL(MOdu << 3, _1s << 2);
outlet_wave = wave;
