uint32_t phase;
uint32_t Phase;
int32_t sine;
int32_t read;
uint32_t Penv;
uint32_t Venv;
uint32_t Wenv;
int gtrig;
int Gtrig;
int32_t noise;
int32_t val;
int32_t table1;
int32_t table2;
int32_t preset;
int32_t count;
int32_t mix;
int32_t tablemix(int32_t WaveA, int32_t WaveB, int32_t Mix) {
  mix = ___SMMUL(((1 << 27) - Mix) << 3, WaveA << 2) +
        ___SMMUL(Mix << 3, WaveB << 2);
}
int i;
int32_t MIX1;
int32_t W[2];
int32_t array[19];
int prev;
int trig;
int select;
int pv;
int last;
int DO;
int cnt;
int next;
uint32_t PLFO;

array[0] = param_Vdec;
array[1] = param_Pdec;
array[2] = param_Watt;
array[3] = param_rate; ////////
array[4] = param_phase;
array[5] = param_MW; ///////////
array[6] = param_pitch;
array[7] = param_Pamt;
array[8] = param_FM;
array[9] = param_env2wave;
array[10] = param_mix;
array[11] = param_hrm;
array[12] = param_wave;
array[13] = param_quant;
array[14] = param_step;
array[15] = param_sineLvl;
array[16] = param_waveLvl;
array[17] = param_start;
array[18] = param_gain;

if (!(DO == (next >> 3))) {
  cnt = 0;
  last = select;
  select = next >> 3;

  MidiSend3((midi_device_t)MIDI_DEVICE_USB_HOST, 1, MIDI_NOTE_ON + 1,
            select << 1, 64);
  MidiSend3((midi_device_t)MIDI_DEVICE_USB_HOST, 1, MIDI_NOTE_OFF + 1,
            last << 1, 64);
}

if (!(param_control == pv)) {
  MidiSend3((midi_device_t)MIDI_DEVICE_USB_HOST, 1, MIDI_CONTROL_CHANGE, 3,
            __USAT((param_control >> 20), 8));
}

if (!(select == prev)) {
  PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_control],
                     __USAT(array[select], 28), 0xFFFD);
}
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Vdec + select],
                   __USAT(param_control, 28), 0xFFFD);

PLFO += inlet_timing * ((param_rate >> 22) + 1) * inlet_Xrate;
int32_t LFO;
SINE2TINTERP(PLFO + (param_phase << 5) + (1 << 30), LFO)
LFO = ___SMMUL(LFO, param_MW - (1 << 26) << 2);

int32_t MiX1 =
    inlet_mix + param_mix + ___SMMUL(param_env2wave << 3, Venv + LFO);
MiX1 = MiX1 & ((1 << 27) - 1);
int32_t quant = (param_quant >> 21) + 1;
float32_t step =
    ((float32_t)(attr_table.Waveforms)) / (quant) * (param_step >> 21);
outlet_div = quant;

W[0] = ((MiX1 >> 4) * quant) >> 23;
MiX1 = (MiX1 - (W[0] << 27) / quant) * quant;
W[1] = W[0] * step + step + (param_wave >> 20);
W[0] = W[0] * step + (param_wave >> 18);

for (i = 0; i < 2; i++) {
  W[i] = (W[i] - (W[i] / attr_table.Waveforms) * attr_table.Waveforms);
  W[i] = W[i] < 0 ? W[i] + attr_table.Waveforms : W[i];
  W[i] = W[i] * attr_table.LENGTH;
}

int32_t F1;
MTOF(-param_Pdec, F1)
int32_t F2;
MTOF(-(param_Vdec), F2)
F2 = F2 >> 2;
int32_t F4;
MTOF(-param_Watt, F4)
if (count >= param_hold) {
  Penv = ___SMMLA(-Penv, F1 << 1, Penv);
  Venv = ___SMMLA(-Venv, F2 << 1, Venv);
  Wenv = ___SMMLA(-Wenv, F4 << 1, Wenv);
}
if ((inlet_trig > 0) && !gtrig) {
  gtrig = 1;
  Penv = (1 << 27);
  Venv = (1 << 27);
  Wenv = (1 << 27);
  count = 0;
} else if (inlet_trig == 0) {
  gtrig = 0;
}
int hold = param_hold;
count += 1;
count = count > hold ? hold : count;

int32_t PENV = Penv;
PENV = ___SMMUL(PENV << 3, PENV << 2);

int32_t VENV = Venv;
VENV = ___SMMUL(VENV << 3, VENV << 2);
VENV += ___SMMUL(__USAT(param_gain, 28) << 2, VENV << 3);

int32_t WENV = (1 << 27) - Wenv;
WENV = ___SMMUL(WENV << 3, WENV << 2);
WENV = ___SMMUL(WENV << 3, WENV << 2);
// WENV=___SMMUL(WENV<<3,WENV<<2);
WENV = ___SMMUL(WENV << 3, __USAT(param_waveLvl, 28) << 2);

int32_t freq;
int32_t pitch =
    param_pitch + inlet_pitch +
    ___SMMUL(__SSAT((param_Pamt)-param_pitch - inlet_pitch, 29) << 3,
             PENV << 2) -
    (1 << 26);
MTOFEXTENDED(pitch, freq)
freq = freq;

int32_t sineLvl = __USAT(param_sineLvl, 27);
int32_t cut;
MTOF(pitch + ___SMMUL((1 << 30), VENV) + (1 << 27), cut)
outlet_env = Penv;
int32_t FM = ___SMMUL(freq << 1, -param_FM << 4);

prev = select;
pv = param_control;
DO = next >> 3;

if ((inlet_trig > 0) && !Gtrig) {
  PLFO = 0;
  Gtrig = 1;
  phase = 0;
  Phase = 0;
} else if (inlet_trig == 0) {
  Gtrig = 0;
}
Phase += (freq + ___SMMUL(FM << 1, val << 3)) * ((param_hrm >> 22) + 1) >> 4;
phase += freq + ___SMMUL(FM << 1, val << 3);
table1 = ___SMMUL(attr_table.array[((((Phase + (param_start << 5)) >>
                                      32 - attr_table.LENGTHPOW) &
                                     attr_table.LENGTHMASK) +
                                    W[0])]
                      << 3,
                  WENV << 3);
table2 = ___SMMUL(attr_table.array[((((Phase + (param_start << 5)) >>
                                      32 - attr_table.LENGTHPOW) &
                                     attr_table.LENGTHMASK) +
                                    W[1])]
                      << 3,
                  WENV << 3);
tablemix(table1, table2, MiX1);
SINE2TINTERP(phase, sine)
int32_t wave;
wave = __SSAT(___SMMUL(__SSAT(___SMMUL(sine >> 3, sineLvl) +
                                  (__SSAT(___SMMUL(mix << 1, LFO), 28)),
                              28)
                           << 2,
                       VENV << 3)
                  << 5,
              28);
val = ___SMMLA((wave - val) << 1, cut, val);
outlet_out = val >> 1;

if ((status == 0 + MIDI_CONTROL_CHANGE) && (data1 == 10)) {

  if (data2 == 1) {
    next += 1;
  }
  if (data2 == 127) {
    next -= 1;
  }
  next = next - next / 152 * 152;
  next = next < 0 ? next + 152 : next;
}
