uint32_t phase;
int32_t sine;
int32_t v27 = 1 << 27;
uint32_t Penv;
uint32_t Venv;
uint32_t Nenv;

int gtrig;
int Gtrig;
int32_t noise;
int32_t val;
int32_t hp;

int32_t count;

int32_t low;
int32_t band;
int32_t mix;

int i;

int32_t wave;
int32_t PV;
int32_t PP;
int32_t PN;
uint32_t seeds[16];

low = 0;
band = 0;
seeds[8] = 0x21c32332;  // + GenerateRandomNumber();
seeds[9] = 0xfbc57f7a;  // + GenerateRandomNumber();
seeds[10] = 0x7dd1ef4a; // + GenerateRandomNumber();
seeds[11] = 0xe4ec34ad; // + GenerateRandomNumber();
seeds[12] = 0x72007b2f; // + GenerateRandomNumber();
seeds[13] = 0x3d1e9783; // + GenerateRandomNumber();
seeds[14] = 0xa4a8f892; // + GenerateRandomNumber();
seeds[15] = 0xc82c5e28; // + GenerateRandomNumber();
seeds[0] = seeds[8];
seeds[1] = seeds[9];
seeds[2] = seeds[10];
seeds[3] = seeds[11];
seeds[4] = seeds[12];
seeds[5] = seeds[13];
seeds[6] = seeds[14];
seeds[7] = seeds[15];

uint32_t F1;
MTOF(-param_Pdec - inlet_Pdec, F1)
uint32_t F2;
MTOF(-param_Vdec - inlet_Vdec << 1, F2)
F2 = F2 >> 1;
uint32_t F3;
MTOF(-(param_Ndec - inlet_Ndec << 1) + (1 << 26), F3)
int32_t Seed = param_seed + inlet_seed;
if (count >= param_hold) {
  Penv = ___SMMLA(-Penv, F1 << 1, Penv);
  Venv = ___SMMLA(-Venv, F2 << 1, Venv);
  Nenv = ___SMMLA(-Nenv, F3 << 1, Nenv);
}
if ((inlet_trig > 0) && !gtrig) {
  seeds[0] = seeds[8] + Seed;
  seeds[1] = seeds[9] + Seed;
  seeds[2] = seeds[10] + Seed;
  seeds[3] = seeds[11] + Seed;
  seeds[4] = seeds[12] + Seed;
  seeds[5] = seeds[13] + Seed;
  seeds[6] = seeds[14] + Seed;
  seeds[7] = seeds[15] + Seed;
  gtrig = 1;
  Penv = (1 << 27);
  Venv = inlet_trig;
  Nenv = (1 << 27);
  count = 0;
  phase = 0;
} else if (inlet_trig == 0) {
  gtrig = 0;
}
int hold = param_hold + inlet_hold;
count += 1;
count = count > hold ? hold : count;

int32_t PENV = Penv;
PENV = ___SMMUL(PENV << 3, PENV << 2);

int32_t VENV = Venv;
VENV = ___SMMUL(VENV << 3, VENV << 2);

VENV += ___SMMUL(__USAT(param_gain + inlet_gain, 27) << 2, VENV << 3) * 3;

int32_t NENV = ___SMMUL(Nenv << 3, Nenv << 2);
NENV = ___SMMUL(NENV << 3, NENV << 2);
NENV = ___SMMUL(NENV << 3, (__USAT(param_noiseLvl + inlet_noiseLvl, 27)) << 2);

int32_t freq;
MTOFEXTENDED(
    param_pitch + inlet_pitch +
        ___SMMUL(__SSAT(param_Pamt + inlet_Pamt - param_pitch - inlet_pitch, 28)
                     << 3,
                 PENV << 2),
    freq)
freq = freq;
int32_t damp = (0x80 << 24) - (__USAT(param_reso + inlet_reso, 27) << 4);
damp = ___SMMUL(damp, damp);
int32_t alpha;
int32_t fraq;
MTOFEXTENDED(__SSAT(param_cut + inlet_cut +
                        ___SMMUL(__SSAT(param_E2C + inlet_E2C, 28) << 3,
                                 NENV << 2),
                    28),
             alpha);
SINE2TINTERP(alpha, fraq);

int32_t sineLvl = __USAT(param_sineLvl + inlet_sineLvl, 27);
int32_t cut;
cut = param_LP + ___SMMUL(__SSAT(param_E2C + inlet_E2C, 28) << 3, VENV << 2);
// preset=(param_wave+inlet_waveform);
// preset=preset-preset/attr_table.Waveforms*attr_table.Waveforms;
// preset=preset<<attr_table.LENGTHPOW;
outlet_Penv = PENV;
outlet_Venv = __USAT(VENV, 27);
int32_t Noise = (1 << 28) - (__SSAT(param_cut + inlet_cut, 28) + (1 << 27));
int32_t FM = ___SMMUL(freq << 1, param_FM + inlet_FM << 3);

int32_t Vstp = (VENV - PV) >> 4;
int32_t Pstp = (PENV - PP) >> 4;
int32_t Nstp = (NENV - PN) >> 4;
int32_t IV = PV;
int32_t IP = PP;
int32_t IN = PN;
PV = VENV;
PP = PENV;
PN = NENV;

IV += Vstp;
IP += Pstp;
IN += Nstp;

int i;
int32_t n = 0;
for (i = 0; i < 8; i++) {
  seeds[i] = (seeds[i] * 196314165) + 907633515;
  n += ((int32_t)(seeds[i])) >> 7;
}
noise = n;
int32_t notch = (noise) - (___SMMUL(damp, band) << 1);
low = low + (___SMMUL(fraq, band) << 1);
int32_t high = notch - low;
band = (___SMMUL(fraq, high) << 1) + band;
int32_t out;
switch ((param_mode + inlet_mode) & 3) {
case 0:
  out = low;
  break;
case 1:
  out = high;
  break;
case 2:
  out = band;
  break;
case 3:
  out = notch;
  break;
}

noise = out << 4;
int32_t tmp = val;
int32_t over = v27 - (tmp > 0 ? tmp : -tmp);
if (param_FM < 0) {
  tmp = tmp > 0 ? over : -tmp;
} else {
  tmp = tmp > 0 ? -tmp : tmp;
}
hp += tmp - hp >> 9;
phase += freq + ___SMMUL(NENV, out >> 2) + (___SMMUL(FM, tmp - hp) << 8);

SINE2TINTERP(phase, sine)

wave =
    __SSAT(___SMMUL(
               ___SMMUL(sine, sineLvl) +
                       __SSAT((___SMMUL((noise >> 2) +
                                            (___SMMUL(noise, Noise << 3) << 3),
                                        IN << 2)),
                              28)
                   << 2,
               IV << 1)
               << 2,
           28)
    << 1;
int32_t Cut;
MTOF(cut - ((wave > 0 ? wave : -wave) << 2), Cut)
val = ___SMMLA((wave - val) << 1, Cut, val);

outlet_out = val;
