uint32_t P[2];
int32_t R[2];
int32_t S[2];
int32_t V[2];
int32_t C[2];
int32_t N[2];
bool trig;
int32_t env;
int32_t Env;
int i;
int32_t low[2];
int32_t band[2];
int32_t freq[2];
int32_t Vdec;
int32_t Pdec;

env = env - ___SMMUL(Vdec, env);
Env = Env - ___SMMUL(Pdec, Env);
if (((inlet_trigOpen + inlet_trigClosed) > 0) && !trig) {
  trig = 1;
  if (inlet_trigOpen > 0) {
    env = (__USAT(inlet_trigOpen, 27));
    Env = (__USAT(inlet_trigOpen, 27));
    MTOF(-(param_hitO << 1) + ___SMMUL(inlet_negDec << 2, param_hitO << 2) +
             (1 << 27),
         Pdec)
    MTOF(-(param_tailO << 1) + ___SMMUL(inlet_negDec << 2, param_tailO << 2) +
             (1 << 27),
         Vdec)
  }
  if (inlet_trigClosed > 0) {
    MTOF(-(__SSAT((param_hitC << 1) -
                      ___SMMUL(inlet_negDec << 2, param_hitC << 2),
                  28)) +
             (1 << 27),
         Pdec)
    MTOF(-(__SSAT((param_tailC << 1) -
                      ___SMMUL(inlet_negDec << 2, param_tailC << 2),
                  28)) +
             (1 << 27),
         Vdec)
    env = (__USAT(inlet_trigClosed, 27));
    Env = (__USAT(inlet_trigClosed, 27));
  }
} else if ((inlet_trigOpen + inlet_trigClosed) == 0) {
  trig = 0;
}

int32_t Venv = env;
int32_t Penv = Env > (1 << 26) ? (1 << 27) : 0;
Venv = ___SMMUL(Venv << 3, Venv << 2);
outlet_o1 = Env;

Venv = Penv > Venv ? Penv : Venv >> 1;
// Venv=___SMMUL(Venv<<3,Venv<<2);
// Venv=___SMMUL(Venv<<3,Venv<<2);
// Venv=___SMMUL(Venv<<3,Venv<<2);

int32_t p1 = (param_fA + inlet_pitch >> 2) + (1 << 26);
int32_t p2 = (param_fB >> 2);
int32_t Pamt = (param_Pamt >> 2) + (1 << 26);
MTOFEXTENDED(p1 + (Penv > 0 ? Pamt - p1 : 0), R[0])

MTOFEXTENDED(p1 + p2 + (Penv > 0 ? Pamt - p1 - p2 : 0), R[1])
MTOF(p1 + param_cut + (Penv >> 1) - (1 << 32), C[0])
MTOF(p1 + p2 + param_cut + (Penv >> 1) - (1 << 32), C[1])
int32_t mix = __USAT(param_AmixB + Vdec, 27);
int32_t cmix = (1 << 27) - mix;

int32_t damp = (0x80 << 24) - (param_reso << 4);
damp = ___SMMUL(damp, damp);
int32_t alpha;

MTOFEXTENDED(__SSAT(p1 + param_cut + (Penv >> 1) - (1 << 32), 28), alpha);
SINE2TINTERP(alpha, freq[0]);
MTOFEXTENDED(__SSAT(p1 + p2 + param_cut + (Penv >> 1) - (1 << 32), 28), alpha);
SINE2TINTERP(alpha, freq[1]);

int32_t noise = (int32_t)(GenerateRandomNumber)();
if (noise > 0) {
  N[0] += noise - (1 << 31);
} else {
  N[1] += noise + (1 << 31);
}

for (i = 0; i < 2; i++) {
  int32_t notch = N[i] - (___SMMUL(damp, band[i]) << 1);
  low[i] = low[i] + (___SMMUL(freq[i], band[i]) << 1);
  int32_t high = notch - low[i];
  band[i] = (___SMMUL(freq[i], high) << 1) + band[i];
  P[i] += R[i];
  V[i] = ___SMMLA(((S[i] >> 4) - V[i]) << 1, C[i], V[i]);
  S[i] = P[i] +
         (___SMMUL(___SMMUL(___SMMUL(param_FM << 3, (1 << 27) - Venv << 2) << 1,
                            high << 2)
                       << 4,
                   V[(i + 1) & 1] - S[i] << 2)
          << 3);
  S[i] = S[i] > 0 ? (1 << 27) : (-1 << 27);
}
outlet_out =
    ___SMMUL(___SMMUL(cmix, S[0]) + ___SMMUL(mix << 3, S[1]) << 2, Venv << 3);
