int32_t Agate;
int32_t Dgate;
int32_t Rgate;
int32_t val;
int32_t RAval;
int32_t RDval;
int32_t Aval;
int32_t Dval;
int32_t Rval;
int32_t DLvl;
int32_t RLvl;
int32_t RRval;
int32_t t;
int32_t AOval;
int32_t DOval;
int32_t ROval;
int32_t RRel;
int32_t Rdel;
int32_t Adel;

int32_t Agate = 0;
int32_t Dgate = 0;
int32_t Rgate = 0;
Aval = 0;

// ATTACK
Agate = inlet_gate;
if ((Agate > 0) & (ROval > 0)) {
  Aval = ___SMMUL(ROval << 3, RRval << 2);
}
MTOF(-param_ATim, t);
if ((Agate > 0) & (Aval < ((1 << 27) - 1 - (t >> 7)))) {

  Aval = Aval + (t >> 7);
  RAval = Aval;
} else {
  if (Agate > 0) {
    Aval = (1 << 27);
    Dgate = (1 << 27);
    RAval = Aval;
  } else {
    RAval = Aval;
    Aval = 0;
  }
}

// BEZIER ATTACK
{
  int(x1) = RAval;
  int(y1) = ((1 << 27) - RAval);
  int p0 = 0;
  int p1 = inlet_A1;
  int p2 = inlet_A2;
  int p3 = inlet_A3;
  int p4 = (1 << 27);

  int x2 = ___SMMUL(x1 << 3, x1 << 2);
  int x3 = ___SMMUL(x2 << 3, x1 << 2);
  int x4 = ___SMMUL(x3 << 3, x1 << 2);
  int y2 = ___SMMUL(y1 << 3, y1 << 2);
  int y3 = ___SMMUL(y2 << 3, y1 << 2);
  int y4 = ___SMMUL(y3 << 3, y1 << 2);

  int a = ___SMMUL(y4 << 3, p0 << 2);
  int b = ___SMMUL(x1 << 4, ___SMMUL(y3 << 3, p1 << 2) << 1) * 4;
  int c = ___SMMUL(x2 << 4, ___SMMUL(y2 << 3, p2 << 2) << 1) * 6;
  int d = ___SMMUL(x3 << 4, ___SMMUL(y1 << 3, p3 << 2) << 1) * 4;
  int e = ___SMMUL(x4 << 3, p4 << 2);
  int f = AOval = a + b + c + d + e;

  // SUSTAIN
  DLvl = (AOval)-param_SLvl;
  if (Agate == 0) {
    Dgate = 0;
  }

  // DECAY
  MTOF(-param_DTim, t);
  if ((Dgate > 0) & (Dval < ((1 << 27) - 1 - (t >> 7)))) {

    Dval = Dval + (t >> 7);
    RDval = Dval;
  } else {
    if ((Dgate > 0) & (Dval > ((1 << 27) - 1 - (t >> 7)))) {
      Dval = (1 << 27);
      RDval = Dval;
    } else if (Dgate == 0) {
      RDval = Dval;
      Dval = 0;
    }
  }

  // BEZIER DECAY
  {
    int(x1) = RDval;
    int(y1) = ((1 << 27) - RDval);
    int p0 = 0;
    int p1 = inlet_D1;
    int p2 = inlet_D2;
    int p3 = inlet_D3;
    int p4 = (1 << 27);

    int x2 = ___SMMUL(x1 << 3, x1 << 2);
    int x3 = ___SMMUL(x2 << 3, x1 << 2);
    int x4 = ___SMMUL(x3 << 3, x1 << 2);
    int y2 = ___SMMUL(y1 << 3, y1 << 2);
    int y3 = ___SMMUL(y2 << 3, y1 << 2);
    int y4 = ___SMMUL(y3 << 3, y1 << 2);

    int a = ___SMMUL(y4 << 3, p0 << 2);
    int b = ___SMMUL(x1 << 4, ___SMMUL(y3 << 3, p1 << 2) << 1) * 4;
    int c = ___SMMUL(x2 << 4, ___SMMUL(y2 << 3, p2 << 2) << 1) * 6;
    int d = ___SMMUL(x3 << 4, ___SMMUL(y1 << 3, p3 << 2) << 1) * 4;
    int e = ___SMMUL(x4 << 3, p4 << 2);
    int f = DOval = a + b + c + d + e;
  }
  RDval = ___SMMUL(DOval << 3, DLvl << 2);

  // RELEASE
  if ((Agate == 0) & (((AOval) - (RDval)) > 0)) {
    Rval = ((1 << 27));
    RRval = (AOval) - (RDval);
  }
  if (!((Agate == 0) & (((AOval) - (RDval)) > 0))) {
    MTOF(-param_RTim, t);
    if ((Agate == 0) & ((Rval - (t >> 7)) > 0)) {

      Rval = Rval - (t >> 7);
    } else {
      Rval = 0;
    }
  }
  RRel = Rdel;
  Rdel = Rval;
}

// BEZIER RELEASE
{
  int(x1) = RRel;
  int(y1) = ((1 << 27) - RRel);
  int p0 = 0;
  int p1 = (1 << 27) - inlet_R3;
  int p2 = (1 << 27) - inlet_R2;
  int p3 = (1 << 27) - inlet_R1;
  int p4 = (1 << 27);

  int x2 = ___SMMUL(x1 << 3, x1 << 2);
  int x3 = ___SMMUL(x2 << 3, x1 << 2);
  int x4 = ___SMMUL(x3 << 3, x1 << 2);
  int y2 = ___SMMUL(y1 << 3, y1 << 2);
  int y3 = ___SMMUL(y2 << 3, y1 << 2);
  int y4 = ___SMMUL(y3 << 3, y1 << 2);

  int a = ___SMMUL(y4 << 3, p0 << 2);
  int b = ___SMMUL(x1 << 4, ___SMMUL(y3 << 3, p1 << 2) << 1) * 4;
  int c = ___SMMUL(x2 << 4, ___SMMUL(y2 << 3, p2 << 2) << 1) * 6;
  int d = ___SMMUL(x3 << 4, ___SMMUL(y1 << 3, p3 << 2) << 1) * 4;
  int e = ___SMMUL(x4 << 3, p4 << 2);
  int f = ROval = a + b + c + d + e;
}
if (Agate > 0) {
  ROval = 0;
}
// OUTCOME
outlet_out =
    (AOval)-___SMMUL(DOval << 3, DLvl << 2) + ___SMMUL(ROval << 3, RRval << 2);

Adel = Agate;
