uint32_t v31 = (uint32_t)1 << 31;
uint32_t v30 = (uint32_t)1 << 30;
int32_t outL;
int32_t outR;
int32_t lowL;
int32_t bandL;
int32_t phs;
int32_t lowR;
int32_t bandR;
int32_t rate;
int32_t depth;
int32_t reso;
int32_t Mod;
int32_t F1;
int32_t F2;
int32_t FD;
int32_t pitch;
bool bypass, solo;
int mode;
int32_t SOFT(int32_t in) {
  int32_t ts = __SSAT(in, 28);
  int32_t tsq31 = ts << 3;
  int32_t tsq31p3 = ___SMMUL(tsq31, ___SMMUL(tsq31, tsq31));
  return ts = (ts + (ts >> 1) - (tsq31p3)) * 3 >> 2;
}
int32_t FX(int32_t inL, int32_t inR, int32_t CV1, int32_t CV2) {
  int32_t damp = (0x80 << 24) - (__USAT(reso, 27) << 4);
  damp = ___SMMUL(damp, damp);
  int32_t alpha;
  int32_t freq;

  MTOFEXTENDED(FD + CV2, rate);
  rate = rate >> 8;
  phs += rate + (___SMMUL(CV2, rate) << 4);
  SINE2TINTERP(phs, F1)
  F1 = ___SMMUL(depth, F1 >> 2);
  int32_t TP = 0;
  switch (mode & 3) {
  case 0:
    TP = (12 << 21);
    break;
  case 1:
    TP = -(24 << 21);
    break;
  default:;
    break;
  }
  MTOFEXTENDED(pitch + (CV1 >> 1) + F1 + TP + (___SMMUL(Mod, bandL) << 4),
               alpha);
  SINE2TINTERP(alpha, freq);

  int32_t notch = inL - (___SMMUL(damp, bandL) << 1);
  lowL = lowL + (___SMMUL(freq, bandL) << 1);
  int32_t high = notch - lowL;
  bandL = (___SMMUL(freq, high) << 1) + bandL;
  switch (mode & 3) {
  case 0:
    outL = lowL;
    break;
  case 1:
    outL = high;
    break;
  case 2:
    outL = bandL;
    break;
  case 3:
    outL = notch;
    break;
  }
  TP = 0;
  switch (((mode & 3) + (mode >> 2)) & 3) {
  case 0:
    TP = (12 << 21);
    break;
  case 1:
    TP = -(24 << 21);
    break;
  default:;
    break;
  }
  MTOFEXTENDED(pitch + (CV1 >> 1) + F1 + TP - (___SMMUL(Mod, bandR) << 4),
               alpha);
  SINE2TINTERP(alpha, freq);
  notch = inR - (___SMMUL(damp, bandR) << 1);
  lowR = lowR + (___SMMUL(freq, bandR) << 1);
  high = notch - lowR;
  bandR = (___SMMUL(freq, high) << 1) + bandR;
  switch (((mode & 3) + (mode >> 2)) & 3) {
  case 0:
    outR = lowR;
    break;
  case 1:
    outR = high;
    break;
  case 2:
    outR = bandR;
    break;
  case 3:
    outR = notch;
    break;
  }
  if (bypass > 0) {
    outL = inL;
    outR = inR;
  }
};

lowL = 0;
bandL = 0;
lowR = 0;
bandR = 0;

depth = param_depth;
Mod = param_mod;
pitch = param_cutoff;
reso = param_reso;
FD = param_rate;
bypass = param_bypass;
solo = param_solo;
mode = (param_mode + inlet_mode);
