latch8x

$\text{[math]}$

multiply

Author: Johannes Taelman

License: BSD

Github: sss/logic/latch8x.axo

Inlets

frac32 i1

frac32 i2

frac32 i3

frac32 i4

frac32 i5

frac32 i6

bool32 trg

Outlets

frac32 o1

frac32 o2

frac32 o3

frac32 o4

frac32 o5

frac32 o6

Declaration

bool trg;
int in[6];

Control Rate

if ((inlet_trg > 0) && !trg) {
  trg = 1;
  in[0] = inlet_i1;
  in[1] = inlet_i2;
  in[2] = inlet_i3;
  in[3] = inlet_i4;
  in[4] = inlet_i5;
  in[5] = inlet_i6;
} else if (inlet_trg < 1) {
  trg = 0;
}

outlet_o1 = in[0];
outlet_o2 = in[1];
outlet_o3 = in[2];
outlet_o4 = in[3];
outlet_o5 = in[4];
outlet_o6 = in[5];
