int32 adds to respective value
int32 adds to respective value
int32 adds to respective value
int32 adds to respective value
int32 select parameter to change (0 to 17)
frac32.positive input for controlling parameters
bool32.rising Trigger high updates parameter to "in" inlet
frac32 FMW
frac32 adds to respective value, so no need for external adders.
frac32 adds to respective value
frac32 adds to respective value
frac32 adds to respective value
frac32 adds to respective value
frac32 adds to respective value
frac32 Algo
frac32 ShiftStep
frac32 ShiftHalf
frac32 ShiftSec
frac32 ShiftThr
frac32 FMW
frac32 Walk
frac32 SprdM
frac32 Sprd1
frac32 Sprd2
frac32 SprdE
frac32 AM
frac32 Algo
frac32 ShiftStep
frac32 ShiftHalf
frac32 ShiftSec
frac32 ShiftThr
int32 Connect all parameters to corresponding inputs of the quad counter module or several single counter modules.
int32 Step2
int32 Range
int32 Minimum
int32 Step1
int32 Step2
int32 Range
int32 Minimum
frac32.s.map FMW
frac32.s.map Walk
frac32.s.map SprdM
frac32.s.map Sprd1
frac32.s.map Sprd2
frac32.s.map SprdE
frac32.s.map AM
frac32.s.map Algo
frac32.s.map ShiftStep
frac32.s.map ShiftHalf
frac32.s.map ShiftSec
frac32.s.map ShiftThr
int32_t cache;
int trg;
switch (inlet_sel > 0 ? inlet_sel : 0) {
case 0:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_FMW],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 1:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Walk],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 2:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_SprdM],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 3:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Sprd1],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 4:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Sprd2],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 5:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_SprdE],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 6:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_AM], inlet_in,
0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 7:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Step1],
(inlet_in >> 19) + 257, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 8:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Step2],
(inlet_in >> 19) + 256, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 9:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Range],
(inlet_in >> 19) + 257, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 10:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Minimum],
(inlet_in >> 19) + 257, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 11:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_Algo],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 12:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_ShiftStep],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 13:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_ShiftHalf],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 14:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_ShiftSec],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
case 15:
if ((inlet_trg > 0) && (trg != 1)) {
trg = 1;
PExParameterChange(&parent->PExch[PARAM_INDEX_attr_legal_name_ShiftThr],
inlet_in, 0xFFFD);
} else {
if (inlet_trg == 0) {
trg = 0;
}
}
break;
}
outlet_FMW = param_FMW + inlet_FMW;
outlet_Walk = param_Walk + inlet_Walk;
outlet_SprdM = param_SprdM + inlet_SprdM;
outlet_Sprd1 = param_Sprd1 + inlet_Sprd1;
outlet_Sprd2 = param_Sprd2 + inlet_Sprd2;
outlet_SprdE = param_SprdE + inlet_SprdE;
outlet_AM = param_AM + inlet_AM;
outlet_Step1 = param_Step1 + inlet_Step1;
outlet_Step2 = param_Step2 + inlet_Step2;
outlet_Range = param_Range + inlet_Range;
outlet_Minimum = param_Minimum + inlet_Minimum;
outlet_Algo = param_Algo + inlet_Algo;
outlet_ShiftStep = param_ShiftStep + inlet_ShiftStep;
outlet_ShiftHalf = param_ShiftHalf + inlet_ShiftHalf;
outlet_ShiftSec = param_ShiftSec + inlet_ShiftSec;
outlet_ShiftThr = param_ShiftThr + inlet_ShiftThr;
