uint32_t phase;
uint32_t Phase;
float32_t slope1n;
uint64_t slope1d;
uint64_t slope1e;
int32_t out;
int32_t sine;
int64_t val;
int32_t Slope;
int32_t Shift;
int32_t Fmw;
int32_t FMW;
int32_t vil;
int32_t HP;
int32_t freq;
int32_t saturate;
float32_t scale;

if (inlet_active > 0) {
  MTOF(param_pitch + inlet_pitch, freq)
  saturate = ((1 << 27) - (param_saturate + inlet_saturate)) + 64;
  saturate = saturate < 64 ? 64 : saturate;
  saturate = saturate > ((1 << 27) - 64) ? ((1 << 27) - 64) : saturate;
  scale = (float)1 /
          (((float)(1 << 28)) / ((float)((1 << 28) + ((saturate) << 3))));
}

if (inlet_active > 0) {
  int32_t slape = __SSAT(param_slope + inlet_slope, 28);
  Slope = Slope + ((slape - Slope) >> 6);
  int32_t shaft = __SSAT(param_shift + inlet_shift, 28);
  Shift = Shift + (((1 << 27) - shaft - Shift) >> 6);
  int32_t fmw = __SSAT(param_FM + inlet_FMW, 29);
  Fmw = Fmw + ((fmw - Fmw) >> 6);
  FMW = ___SMMUL(inlet_freq << 4, (Fmw) << 2);
  phase += freq + ___SMMUL(FMW << 4, freq << 4);
  Phase = phase + (inlet_phase << 5);
  slope1d = (1 << 27) - Slope;
  if (Phase < (Slope << 5)) {
    slope1n = ((float)((1 << 31))) / ((float)(Slope));
    out = ((Phase >> 5) * slope1n) + (Shift << 3);
  } else {
    slope1n = ((float)((1 << 31))) / ((float)(slope1d));
    out = -(((Phase - (Slope << 5)) >> 5) * slope1n) - (Shift << 3);
  }
  if (param_sine > 0) {
    SINE2TINTERP(out, sine)
  } else {
    sine = out << 1;
  }
  val = val + ((sine - val) >> 2);
  int32_t vol = val >= 0 ? val >> 3 : -val >> 3;
  int32_t dir = val >= 0 ? 1 : -1;
  int32_t ccomp = (((float)(vol)) / ((float)(vol + ((saturate) << 3)))) *
                  (1 << 27) * dir * scale;
  vil = vil + ((ccomp - vil) >> 1);
  HP = HP + ((vil - HP) >> 9);
  outlet_out = (vil - HP) >> 1;
}
