// updates the coefficients with the "ZDF" step invariant method.
void update(float _Q, float F) {
  D = _Q;
  // _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
  // pre iterations values (equiv to Chamberlin filter)
  float _a = F * F;
  float tmp = 1 - _a - D * F;
  float _b = F * tmp + F;
  float _c = tmp * tmp - _a;
  // _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
  // 3 iterations to obtain the new a b and c (equiv x8 oversampling)
  // Two sets of vars (_a _b _c and a b c) are used to bounce values
  // between iterations to optimize copies.
  float b2;
  b2 = _b * _b;
  a = b2 + _a * (2 - _a);
  b = _b * (1 + _c - _a);
  c = _c * _c - b2;
  b2 = b * b;
  _a = b2 + a * (2 - a);
  _b = b * (1 + c - a);
  _c = c * c - b2;
  b2 = _b * _b;
  a = b2 + _a * (2 - _a);
  b = _b * (1 + _c - _a);
  c = _c * _c - b2;
  // b2 = b * b; _a = b2 + a * (2 - a); _b = b *(1 + c - a); _c = c * c - b2;
  // b2 = _b * _b; a = b2 + _a * (2 - _a); b = _b *(1 + _c - _a); c = _c * _c -
  // b2;
}

float a, b, c; // current values (srate interpolated)
float q;
float D;        // used for hp
float x;        // input
float lp, bp;   // state variables/outputs
float lp2, bp2; // state variables/outputs of 24dB output
float TRF_coef;

TRF_coef = (758.0f / (1 << 27)) * 2 * 3.1415926535f / (8 * 48000);

D = x = lp = bp = 0;
update(1.0f, 0.1f / 8);

q = __USAT(param_Q + inlet_reso, 27) * (1.0f / (1 << 27));
q = 0.25f + q * (1 + q * q * (18.75f + q * 60)); // 0.25 -> 80
q = 1 / (2 * q);

int32_t alpha;
MTOFEXTENDED(inlet_pchMod + param_pitch + inlet_pitch, alpha);
update(q, alpha *TRF_coef);

x = (float)inlet_in;
// _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
float x_lp = x - lp;
outlet_lp12 = (int32_t)(lp += a * x_lp + b * bp);
outlet_hp12 = (int32_t)(x - D * bp - lp);
outlet_bp6 = (int32_t)(bp = b * x_lp + c * bp);
