int32_t y[8], seq[6], v, integ;
float p, dp, _64dp, pM, dpM, _dpM, _64dpM;
uint8_t cpt;
uint8_t i;

cpt = 0;
p = pM = 0;
y[0] = y[1] = y[2] = y[3] = y[4] = y[5] = y[6] = y[7] = v = integ = 0;
i = 0;

int32_t idp;
MTOFEXTENDED(param_pitch_space_slave + inlet_pitch_space_slave, idp);
dp = 6.0f * (idp * (0.25f / (1 << 30)));
if (dp > 1)
  dp = 1;
_64dp = 64.0f / dp;
seq[0] = param_level0 >> 9;
seq[1] = param_level1 >> 9;
seq[2] = param_level2 >> 9;
seq[3] = param_level3 >> 9;
seq[4] = param_level4 >> 9;
seq[5] = param_level5 >> 9;
// _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
MTOFEXTENDED(param_pitch_space_master + inlet_pitch_space_master, idp);
dpM = (idp * (0.25f / (1 << 30)));
if (dpM > 1)
  dpM = 1;
_dpM = 1 / dpM;
_64dpM = 64.0f * _dpM;

// phase increment
pM += dpM; // Master
p += dp;   // Slave
// _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
//                                                         synchro ?
if (pM >= 1) { // phase above 1
  pM -= 1;     // reset Master phase
  float aM = pM * _64dpM;

  // The slave can reset itself in the same sample interval than a sync
  // we take account of it if it happens before the sync
  if (p >= 1) {
    p -= 1;
    float a = p * _64dp;
    if (a > aM) {   // slave before master
      cpt++;        // next step in sequence
      if (cpt >= 6) // above 6 => wrap to 0
        cpt = 0;
      // select the band limited pulse according to subsample time since the
      // transition
      const int16_t *t = tiar_bli_8_64 + (((uint32_t)a) << 3);
      int32_t g =
          seq[cpt] -
          v; // gain= the diff between the new step and the current value
      // add the selected band limited pulse to the output 8 taps
      for (int j = 0; j <= 7; j++) {
        y[(i + j) & 7] += g * t[j];
      }
      v += g; // now we can say that the value corresponds to the current step
    }
  }
  //  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _  _
  cpt = 0;            // reset
  p = pM * _dpM * dp; // reset Slave phase taking account of subsample time
  // select the band limited pulse according to subsample time since the
  // transition
  const int16_t *t = tiar_bli_8_64 + (((uint32_t)aM) << 3);
  int32_t g = seq[cpt] -
              v; // gain = the diff between the new step and the current value
  // add the selected band limited pulse to the output 8 taps
  for (int j = 0; j <= 7; j++) {
    y[(i + j) & 7] += g * t[j];
  }
  v += g; // now we can say that the value corresponds to the current step //...
} else {
  // _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
  //                                                         transition ?
  if (p >= 1.0f) { // phase above 1
    cpt++;         // next step in sequence
    if (cpt >= 6)  // above 6 => wrap to 0
      cpt = 0;
    p -= 1.0f; // reset phase
    // select the band limited pulse according to subsample time since the
    // transition
    const int16_t *t = tiar_bli_8_64 + (((uint32_t)(p * _64dp)) << 3);
    int32_t g = seq[cpt] -
                v; // gain= the diff between the new step and the current value
    // add the selected band limited pulse to the output 8 taps
    for (int j = 0; j <= 7; j++) {
      y[(i + j) & 7] += g * t[j];
    }
    v += g; // now we can say that the value corresponds to the current step
  }
}
outlet_out = integ += y[i]; // output integrator
y[i] = 0;
i = (i + 1) & 7;
