frac32.bipolar pitch
bool32 disable
frac32buffer.bipolar out
frac32.s.map.pitch pitch
frac32.s.map level0
frac32.s.map level1
frac32.s.map level2
frac32.s.map level3
frac32.s.map level4
frac32.s.map level5
int32_t y[8], seq[6], v, integ;
float p, dp, dpm, _dp;
uint8_t cpt;
uint8_t i;
float D[6];
float S[6];
cpt = 0;
p = 0;
y[0] = y[1] = y[2] = y[3] = y[4] = y[5] = y[6] = y[7] = v = integ = 0;
i = 0;
D[0] = 1.3f;
D[1] = 0.8f;
D[2] = 0.83f;
D[3] = 0.87f;
D[4] = 0.85f;
D[5] = 0.77f;
float Dtot = D[0];
for (int j = 1; j < 6; j++)
Dtot += D[j];
float coef = 6.0f / Dtot;
for (int j = 0; j < 6; j++) {
D[j] *= coef;
S[j] = 1.0f / D[j];
}
if (!inlet_disable) {
int32_t idp;
MTOFEXTENDED(param_pitch + inlet_pitch, idp);
dp = 6.0f * (idp * (0.25f / (1 << 30)));
if (dp > 0.8f)
dp = 0.8f;
_dp = 1.0f / dp;
dpm = dp * S[cpt];
seq[0] = param_level0 >> 9;
seq[1] = param_level1 >> 9;
seq[2] = param_level2 >> 9;
seq[3] = param_level3 >> 9;
seq[4] = param_level4 >> 9;
seq[5] = param_level5 >> 9;
} else
for (int i = 0; i < BUFSIZE; i++)
outlet_out[i] = 0;
if (!inlet_disable) {
p += dpm; // phase increment
if (p >= 1.0f) { // phase above 1
float a = 1.0f - (1 - (p - dpm)) * _dp * D[cpt];
const int16_t *t = tiar_bli_8_64 + (((uint32_t)(64.0f * a)) << 3);
cpt++; // next step in sequence
if (cpt >= 6) // above 6 => wrap to 0
cpt = 0;
dpm = dp * S[cpt]; // speed change (dp modulation)
// select the band limited pulse according to subsample time since the
// transition
// p -= 1.0f; // reset phase
p = a * dpm;
int32_t g = seq[cpt] -
v; // gain= the diff between the new step and the current value
// add the selected band limited pulse to the output 8 taps
for (int j = 0; j <= 7; j++) {
y[(i + j) & 7] += g * t[j];
}
v += g; // now we can say that the value corresponds to the current step
}
outlet_out = integ += y[i]; // output integrator
y[i] = 0;
i = (i + 1) & 7;
}
